Schneider ILA1B572PC1F0 Lexium ILA Integrated Servo Motor

1. Model Code Definition

• ILA: All-in-one integrated servo (motor + built-in drive) series
• 1: 1st generation Lexium ILA
• B: PROFIBUS-DP fieldbus communication
• 57: 57×57mm square mounting flange
• 2: Medium torque dual-stack rotor specification
• P: Built-in electromagnetic holding brake
• C: Single-turn absolute encoder
• 1: Standard industrial circular connector
• F0: Smooth plain shaft (no keyway)

2. Core Electrical & Performance Parameters

• Supply voltage: DC 24–36V low voltage bus
• Nominal torque: 0.45 N·m
• Continuous current: 7.0 A; Peak current: 8.5 A
• Rated speed: 2600 rpm (24VDC) / Max 4300 rpm (36VDC)
• Encoder: Single-turn absolute, 16384 ppr high resolution
• Safety function: Integrated STO Safe Torque Off, meets SIL2 / PLd safety standard
• Rotor structure: Double stator stack, medium torque & medium speed performance

3. Mechanical & Protection

• Mounting flange: 57×57mm square flange
• Shaft: Φ14mm smooth shaft without key
• Protection grade: IP54 motor body, IP41 shaft end
• Cooling: Natural air convection, fanless maintenance-free
• Weight: Approx 1.9 kg
• Operating temperature: 0°C ~ +50°C, non-condensing environment

4. Communication & Control

• Fieldbus: PROFIBUS-DP, baud rate up to 12 Mbps
• Supports multi-axis synchronous, electronic cam, positioning & speed closed-loop control
• Configured via Lexium CT PC software for parameter tuning and motion programming
• Built-in drive power stage, eliminates separate servo drive cabinet wiring

5. Key Advantages

1. All-in-one integrated design, saves cabinet space, reduces encoder/power cable wiring cost
2. Built-in holding brake, prevents vertical axis falling during power failure
3. Single-turn absolute encoder, no homing required after power cycle
4. STO safety function, meets machine safety standard without external contactors
5. Compact low-voltage DC design, suitable for small standalone automation equipment
6. Full EMC shielding, stable operation near inverters and contactors

6. Typical Application Scenarios

• Small packaging machines: labeling, sorting, carton conveying
• Automated pick-and-place slides, small lifting positioning axes
• Printing, textile, labelling lightweight motion equipment
• Medical automation, electronic assembly equipment
• Small conveyor, dispensing and testing machinery with PROFIBUS PLC control systems
