Schneider MCSESM063F2CU0 Industrial Managed Ethernet Switch

Important Correction

Basic Information

• Model: MCSESM063F2CU0
• Series: Modicon MCS industrial managed fast Ethernet switch
• Mounting: Standard 35mm DIN rail for control cabinet installation
• Operating supply voltage: 9.6 ~ 32 VDC
• Protection grade: IP30 (indoor cabinet use only)
• Operating temperature: 0℃ ~ +60℃

Port Configuration

1. 4 × RJ45 copper electrical ports (10/100 Mbps auto-negotiation)
2. 2 × SC fiber optical ports (multi-mode fiber interface)

   Supports mixed copper + fiber networking to extend long-distance workshop communication.

Core Switch Functions

1. Managed Layer 2 switch, supports VLAN, QoS traffic priority, port mirroring, link aggregation
2. Industrial redundancy protocols: RSTP rapid spanning tree, avoids network loop disconnection
3. Real-time port status LED indicators for link fault quick diagnosis
4. Supports Modbus TCP monitoring, upload switch operating status to PLC/HMI
5. Broadcast storm suppression, anti-interference design for inverter/servo heavy EMI workshop environments

Key Advantages

1. Copper + fiber hybrid ports, solves long-distance transmission signal attenuation problem
2. DIN rail compact design, saves cabinet layout space
3. Full industrial EMC compliance, stable under strong electromagnetic interference from servo drives and contactors
4. Managed function enables network fault remote monitoring and troubleshooting
5. CE, UL industrial safety certified, RoHS compliant

Typical Application Scenarios

• Packaging, printing, textile multi-axis servo motion control network
• Factory production line Modbus TCP PLC/HMI communication backbone
• Water treatment, HVAC distributed control system fiber network extension
• Warehouse automation, conveyor equipment long-distance industrial ethernet layout
• Machine cell isolation networking, separating equipment electrical noise via fiber isolation
