Schneider HMIDT952 Harmony GTU Touch Smart Display HMI

Basic Overview

Core Display & Touch Specs

1. Screen Parameters

• Diagonal size: 18.5" TFT color LCD (market labeled as 19W wide)
• Resolution: FWXGA 1366 × 768 pixels, 16 million display colors
• Backlight lifespan: 50,000 hours; built-in ambient brightness auto sensor
• Cooling: Fanless natural convection, zero maintenance

2. Touch Interface

• Multi-touch projected capacitive (PCT) touch screen
• Service life: Up to 50 million touch operations, support multi-point gesture operation
• Front panel protection grade: IP66/IP67, NEMA 4X, dustproof and waterproof for on-machine installation

Electrical & Mechanical Dimensions

• Power supply: 12–24 VDC (allowable range 10.8–28.8 VDC), rated power consumption 19W
• Overall dimension: W483 × H337 × D69 mm, net weight 6.8 kg
• Panel cut-out size: 465(±1) × 319(±1) mm, standard embedded panel mounting
• Operating temperature: 0℃ ~ +55℃ indoor use only

Built-in Interfaces

• USB 2.0 Type-A: For U disk data logging, program upload/download, peripheral connection
• USB 2.0 Mini-B: For PC programming cable connection
• Rear expansion port: Docking with Harmony GTU controller unit for Ethernet, RS485 Modbus, Wi-Fi, remote I/O communication

Main Advantages

1. High-definition wide screen, clear display of multi-group process data, trend curves and alarm records
2. Capacitive multi-touch, smooth operation similar to smart devices, resistant to frequent operation wear
3. High front protection rating, applicable to dusty, splashing water workshop environments
4. Fanless design eliminates fan failure risk, stable long-term continuous operation
5. Matches full series of Harmony GTU control boxes, supports Modbus TCP/IP, OPC UA, remote web access, data logging and recipe management
6. Compliant with CE, cULus, UL508, KC, RCM industrial safety certifications

Typical Application Scenarios

• Food & beverage packaging machinery, filling and labeling lines
• Water treatment, sewage process monitoring systems
• Mining, metallurgy, metal processing equipment
• Large conveyor, lifting and material handling automation
• Printing, textile, plastic molding high-end machine tools
