                      PROSOFT PLX51-PBM PROFIBUS DP Communication Gateway

                      The ProSoft PLX51-PBM is a PROFIBUS DP Master/Slave Communication Gateway that provides connectivity between PROFIBUS DP networks and EtherNet/IP, Modbus TCP/IP, or Modbus Serial networks. It can operate as either a PROFIBUS DP Master or Slave and is especially suited for integration with Rockwell Automation controllers.

                      Key Technical Specifications

                      Parameter	Specification
                      Brand	ProSoft Technology
                      Model	PLX51-PBM
                      Product Type	PROFIBUS DP Communication Gateway
                      PROFIBUS Mode	Master or Slave
                      PROFIBUS Protocol	DPV0 / DPV1
                      PROFIBUS Baud Rate	9.6 kbps to 12 Mbps
                      Cyclic I/O Data	1536 bytes Input / 1536 bytes Output
                      EtherNet/IP	Adapter
                      Ethernet Ports	2 × RJ45
                      Ethernet Speed	10/100 Mbps
                      Ethernet Function	Embedded Switch / DLR capable
                      Modbus TCP/IP	Client or Server
                      Modbus Serial	Master or Slave
                      Serial Interface	RS232 / RS485
                      Power Supply	10–36 VDC
                      Power Consumption	2.04 W @ 24 VDC
                      Operating Temperature	-20 to +70°C
                      Enclosure	IP20, NEMA/UL Open Type
                      Dimensions	149 × 34 × 116 mm
                      Mounting	35 mm DIN Rail

                      The two Ethernet ports can operate as an embedded switch or support Device Level Ring (DLR) topology. The unit also includes one PROFIBUS DP interface and an auxiliary RS232/RS485 interface for Modbus serial communication.

                      Advantages & Features

                      • Supports PROFIBUS DP Master and Slave operation
                      • Converts PROFIBUS DP data to EtherNet/IP
                      • Supports Modbus TCP/IP and Modbus Serial
                      • Supports up to 1536 bytes of input and output cyclic data
                      • Dual Ethernet ports with embedded-switch capability
                      • Built-in PROFIBUS device discovery
                      • PROFIBUS packet-capture diagnostic function
                      • DIN-rail mounting for industrial control cabinets
                      • Wide 10–36 VDC power input
                      • Suitable for Rockwell Automation PLC integration

                      Typical Applications

                      • PROFIBUS-to-EtherNet/IP integration
                      • Rockwell / Allen-Bradley PLC systems
                      • PROFIBUS-to-Modbus communication
                      • Industrial automation networks
                      • Factory automation
                      • Process control
                      • Machine control
                      • Legacy PROFIBUS equipment integration
