Pilz 787532 Safety Relay

Pilz 787532 – Safety Relay

Specifications

• Input: 1/2‑channel wiring, with/without short‑circuit detection across contacts
• Outputs:
  • 3 × N/O (instantaneous safety contacts)
  • 1 × N/C
  • 2 × N/O timed‑delay (0.1–3 s adjustable)
• Supply Voltage (UB): 24–240 V AC/DC
• Rated Current (AC‑1/DC‑1): 8 A max
• Start Modes: Automatic or monitored start
• Terminals: Plug‑in spring‑loaded terminals
• Mounting: DIN rail
• Width: 90 mm
• Operating Temperature: 0 °C to +55 °C
• Certifications: CE, TÜV, cULus, CCC, EAC

Key Features

• Dual‑channel safety: Suitable for category 3 / PL d safety applications
• Time‑delay outputs: 0.1–3 s adjustable for controlled shutdown
• LED indicators: Power, contact status, start circuit
• Redundant & self‑monitoring: Ensures safety even with single‑component failure
• Wide voltage range: Works with 24 VDC up to 240 VAC systems

Applications

• Emergency stop (E‑STOP) monitoring
• Safety gate / door interlock monitoring
• Light curtain & safety sensor evaluation
• Machine tools, packaging, conveyor systems, robotics
