PILZ 773536 Digital Output Expansion Module (PNOZ mo4p)

Product Overview

The PILZ 773536 (model PNOZ mo4p) is a digital output expansion module designed for PNOZmulti modular safety systems. It provides 4 safe relay outputs (NO contacts) with forced-guided contacts to ensure fail-safe operation in industrial automation applications. This module is used to extend the output capacity of PNOZmulti base units, supporting safety functions up to PL e (ISO 13849-1) and SIL 3 (IEC 61508) standards .

Key Features & Technical Specifications

1. Output Configuration

• 4 Normally Open (NO) relay outputs (6A @ 24V DC / 240V AC) .

• Forced-guided contacts to prevent contact welding (critical for safety applications) .

• Suitable for both AC and DC loads (e.g., contactors, valves, indicators) .

2. Integration & Compatibility

• Modular Design: Connects to PNOZmulti base units (e.g., PNOZ m1p, m2p) via spring-clamp or screw terminals

• Expandability: Up to 12 modules can be connected per base unit (8 on the right, 4 on the left) .

• Configuration: Programmable via PNOZmulti Configurator software for custom safety logic .

3. Electrical & Environmental Specs

• Power Supply: 24V DC (sourced from the base unit) .

• Operating Temperature: 0°C to +60°C (humidity tolerance: 93% at 40°C) .

• Protection Rating: IP20 (for control cabinet use) .

• Dimensions: 22.5 mm (W) × 94 mm (H) × 121 mm (D) .

4. Safety Certifications

• CE, cULus, TÜV, EAC, CCC .

• Compliance: EN ISO 13849-1 (PL e), IEC 61508 (SIL 3) .

Applications

1. Emergency Stop Systems: Controls safety contactors in CNC machines or presses .

2. Safety Door Monitoring: Powers interlock devices to prevent unauthorized access .

3. Light Curtain Integration: Triggers machine shutdown when hazards are detected .

Installation & Usage Notes

1. Wiring: Use shielded cables for noise immunity .

2. Testing: Verify contact resistance (<0.1Ω for closed contacts) .

3. Maintenance: Inspect LED indicators for faults (e.g., overload, relay status) .
