MITSUBISHI Q10WCPU-W1-CFE PLC CPU Module

Product Overview

Brand: Mitsubishi Electric
Model: Q10WCPU-W1-CFE
Product Type: MELSEC-Q Series WinCPU Module / PLC CPU Module
Series: MELSEC-Q Series
Application: Industrial Automation, PC-Based Control, Machine Control

The MITSUBISHI Q10WCPU-W1-CFE is a MELSEC-Q Series WinCPU module that integrates PLC control with an industrial PC environment. It runs Windows Embedded Standard 2009 and is designed for advanced automation applications requiring PLC functions combined with PC processing capability.

Technical Specifications

Main Features

• Combines PLC control and industrial PC functions
• Supports Windows-based applications
• Built-in Ethernet communication
• Supports CompactFlash boot operation
• Compatible with MELSEC-Q system architecture
• Suitable for high-performance automation control

Communication Interfaces

Includes:

• Ethernet: 2 channels (10BASE-T / 100BASE-TX / 1000BASE-T)
• RS-232C: 1 channel
• USB 2.0: 5 ports

Suitable for connection with:

• HMI systems
• SCADA software
• Industrial networks
• Peripheral devices

Applications

• Factory automation systems
• Machine control equipment
• Production line management
• Industrial PC-based control
• Data collection and monitoring systems
• Advanced PLC applications
