Mitsubishi MR-BAT6V1SET Servo Amplifier Battery Set

Product Overview

The Mitsubishi MR-BAT6V1SET is a servo amplifier backup battery set designed for Mitsubishi MELSERVO AC Servo Amplifier systems. It is used to maintain the absolute position data of servo motors when the main power supply is turned off, preventing the loss of encoder position information.

This product is an accessory battery, not a servo amplifier itself. It is mainly used with Mitsubishi MR-J4, MR-J5, MR-JE and compatible servo amplifier series.

Main Specifications

• Manufacturer: Mitsubishi Electric
• Model: MR-BAT6V1SET
• Product Type:
  • Servo Amplifier Backup Battery
  • Absolute Encoder Battery Set
  • Servo Drive Accessory
• Application Series: MELSERVO AC Servo Systems
• Compatible Series: MR-J4 / MR-J5 series (depending on amplifier model)
• Battery Type: Lithium Battery Pack
• Nominal Voltage: 6 V
• Capacity: 1650 mAh
• Battery Model: 2CR17335A (CR17335A × 2 cells in series)
• Lithium Content: 1.2 g
• Weight: Approx. 55 g

Technical Function

The MR-BAT6V1SET provides:

• Absolute encoder backup power
• Servo motor position data retention
• Prevention of position loss after power interruption
• Reliable operation of Mitsubishi servo systems

Working principle:

Battery → Servo Amplifier → Encoder Backup Power → Absolute Position Data Retention

Features & Advantages

• Original Mitsubishi MELSERVO accessory
• Maintains servo motor absolute position data
• Compact design for easy installation
• Long service life
• Simple plug-in replacement
• Improves CNC and automation system reliability
• Helps reduce machine re-homing and downtime

Applications

Used in:

• CNC machine tools
• Industrial robots
• Automation production lines
• Packaging machinery
• Semiconductor equipment
• Precision motion control systems

Typical applications:

• Servo motor encoder backup
• CNC axis position retention
• Automated machine maintenance
