Eaton CP8-ME Control Panel

Eaton MFD-CP8-ME Control Panel

Product Description

The Eaton MFD-CP8-ME is a Multi-Function Display (MFD-Titan) CPU / Control Module designed for industrial automation applications. It acts as the central processing and power supply unit of the Eaton MFD-Titan system and can be combined with MFD-80/MFD-80-B display units and I/O expansion modules to create a compact PLC-style control system.

Technical Specifications

• Brand: Eaton / Moeller
• Model: MFD-CP8-ME
• Product Type: Control Panel CPU Module / PLC Controller
• Series: MFD-Titan
• Function: CPU + Power Supply Unit
• Supply Voltage: 24 VDC
• Power Consumption: Approx. 3 W
• Communication Interface: Serial interface
• EasyNet: Not included
• Expansion Capability:
  • Digital I/O modules
  • Analog I/O modules
  • AS-Interface
  • PROFIBUS-DP
  • CANopen®
  • DeviceNet (with compatible modules)
• Memory: Program and screen memory
• Programming Software: easySoft / easySoft-Pro
• Mounting:
  • Direct mounting behind MFD display
  • DIN rail mounting
• Protection Rating: IP20
• Dimensions: Approx. 107.5 × 90 × 30 mm
• Operating Temperature: -25°C to +55°C
• Connection: Screw terminal

Advantages & Features

• Integrated PLC control and display system solution
• Compact design for space-saving installation
• Supports Eaton MFD-Titan operator displays
• Flexible I/O expansion capability
• Suitable for small and medium automation systems
• Provides reliable control, monitoring, and operator interaction
• Easy programming and configuration
• DIN rail installation for industrial cabinets

Applications

• Industrial automation equipment
• Machine control systems
• Control cabinets
• Packaging machinery
• Building automation
• Pump and motor control systems
• Small PLC control applications

Notes / Precautions

• Requires compatible MFD-80 / MFD-80-B display module for operator interface applications
• Verify compatibility with expansion I/O modules before installation
• Confirm 24 VDC power supply requirements
• Check program compatibility before replacement
• Ensure correct wiring and communication configuration
