Eaton MFD-80-B Display Module

Eaton MFD-80-B Display Module

Product Description

The Eaton MFD-80-B is a Multi-Function Display / Operator Interface Module from the MFD-Titan series. It is designed to provide text and graphic visualization, operator control, and parameter display functions when used with Eaton MFD-Titan CPU/power supply modules. It is commonly used as an HMI interface for industrial automation and control systems.

Technical Specifications

• Brand: Eaton
• Model: MFD-80-B
• Product Type: Display Module / HMI Operator Panel
• Series: MFD-Titan
• Display Type: Monochrome LCD
• Resolution: 132 × 64 pixels
• Backlight: Switchable LED backlight
• Keypad: Integrated function keys
• Memory: Display and operating interface functions (when combined with MFD controller modules)
• Supply Voltage: 20.4–28.8 VDC (via compatible MFD module)
• Protection Rating: IP65 (front panel)
• Mounting: Front panel mounting
• Connection Type: Screw terminal / system connection
• Operating Temperature: -25°C to +55°C
• Dimensions: Approx. 86.5 × 86.5 × 21.5 mm
• Weight: Approx. 0.13 kg

Advantages & Features

• Compact HMI display solution for industrial control systems
• Provides text and graphic visualization
• Integrated keypad for operator input and parameter adjustment
• IP65 front protection suitable for control panels
• Supports remote display applications with compatible Eaton MFD modules
• Easy integration into automation cabinets
• Compact design saves installation space

Applications

• Industrial automation equipment
• Machine control panels
• PLC operator interfaces
• Process control systems
• Packaging machinery
• Manufacturing production lines
• Building automation systems

Notes / Precautions

• Requires compatible Eaton MFD-Titan CPU/power supply module for operation
• Confirm communication cable and module compatibility before installation
• Check supply voltage requirements
• Ensure correct panel mounting for maintaining IP65 protection
• Configure display functions according to the control application
