BENTLY 3500/05-01-03-00-00-00 Rack Interface Module / System Rack

Product Overview

Brand: Bently Nevada
Model: 3500/05-01-03-00-00-00
Series: 3500 Machinery Protection System
Product Type: System Rack / Rack Interface Assembly
Function: Provides the mounting platform, power distribution, and communication backplane for Bently Nevada 3500 monitoring modules. It houses vibration monitoring modules, power supplies, and rack interface components to build a complete machinery protection system.

Technical Specifications

• System: Bently Nevada 3500 Monitoring System
• Rack Type: Full-size System Rack
• Rack Size: 19-inch EIA rack
• Module Positions: 14 available module slots
• Mounting Type: Rack mount / panel mount options
• Compatible Modules:
  • 3500/15 Power Supply Module
  • 3500/20 Rack Interface Module
  • 3500/22M Transient Data Interface
  • 3500/42M Proximity Monitor
  • 3500/50 Tachometer Module
  • 3500/60 Temperature Monitor
  • 3500/65 Dynamic Pressure Monitor
• Function:
  • Module installation support
  • Power distribution
  • Internal communication connection
  • System expansion platform
• Installation Position: Power supply and Rack Interface Module occupy the left-side rack positions
• Communication: 3500 proprietary rack communication bus
• Operating Environment: Industrial machinery monitoring applications

Advantages & Features

Modular System Design

Provides a flexible platform for installing multiple Bently Nevada 3500 monitoring modules, allowing customized machinery protection system configurations.

Reliable Backplane Communication

The rack provides internal communication between monitoring modules, ensuring stable data exchange and coordinated system operation.

High System Scalability

Supports up to 14 monitoring module positions, making it suitable for large rotating equipment monitoring systems.

Easy Maintenance & Replacement

Modular plug-in design allows quick installation, replacement, and maintenance of monitoring modules.

Industrial-Grade Reliability

Designed for continuous operation in critical equipment protection applications such as turbines and compressors.

Comprehensive Machinery Protection

Works together with vibration, speed, displacement, and process monitoring modules to provide complete equipment condition monitoring.

Typical Applications

• Steam turbine monitoring systems
• Gas turbine protection systems
• Compressor condition monitoring
• Generator vibration monitoring
• Pump monitoring systems
• Oil & gas production facilities
• Petrochemical plants
• Power generation stations
• Industrial rotating equipment protection

Precautions

• Confirm compatibility with the Bently Nevada 3500 series system before installation.
• Ensure power supply and rack interface modules are installed in the correct positions.
• Check module slot configuration before adding monitoring modules.
• Disconnect system power before installing or removing modules.
• Ensure rack grounding is properly connected.
• Avoid installation in environments with excessive vibration, moisture, or corrosive gases.
• Verify communication and module status after installation.
