BENTLY 13860701 3500 System Module Product Information

Model: 138607-01
Brand: BENTLY NEVADA
Product Type: 3500/22M Transient Data Interface (TDI) Module
Series: 3500 Machinery Protection System
Application: Machinery condition monitoring, vibration data acquisition, and communication interface for rotating equipment protection systems.

Note: 138607-01 is the assembly part number for the Bently Nevada 3500/22M Transient Data Interface Module, which provides the communication link between the 3500 monitoring rack and System 1 machinery management software.

Technical Specifications

• Product Type: Transient Data Interface Module (TDI)
• Series: 3500 Machinery Protection System
• Model: 3500/22M
• Part Number: 138607-01
• Main Function:
  • Data acquisition
  • Rack communication
  • Machinery monitoring data transmission
• Compatible Systems:
  • Bently Nevada 3500 Monitoring System
  • System 1 Machinery Management Software
• Communication Interface:
  • Ethernet 10BASE-T / 100BASE-TX
  • Front USB configuration port
• Communication Protocol:
  • Bently Nevada Host Protocol
• Data Collection:
  • Steady-state data
  • Dynamic waveform data
  • Transient startup/shutdown data
• Rack Position:
  • Slot 1 (next to power supply module)
• Compatible Monitor Modules:
  • 3500/40M Proximitor Monitor
  • 3500/42M Proximitor/Seismic Monitor
  • Other 3500 M-Series monitoring modules
• Power Consumption: Approx. 10.5 W
• Operating Temperature: -30…65 °C
• Storage Temperature: -40…85 °C
• Humidity: Up to 95% RH, non-condensing
• Mounting: 3500 rack installation

Advantages & Features

High-Speed Data Interface

Provides reliable communication between the Bently Nevada 3500 rack and monitoring software for real-time machinery condition analysis.

Integrated Data Acquisition

Combines rack interface functions and communication processor capabilities, allowing continuous collection of machine operating data.

Transient Data Capture

Captures critical machine events such as startup, shutdown, speed changes, and abnormal vibration conditions.

System 1 Compatibility

Works seamlessly with Bently Nevada System 1 software for advanced diagnostics and predictive maintenance.

Reliable Industrial Design

Designed for continuous operation in demanding industrial environments with high reliability.

Easy Maintenance

Modular rack-mounted design allows convenient replacement and system expansion.

Applications

• Steam turbines
• Gas turbines
• Compressors
• Pumps
• Generators
• Rotating machinery monitoring systems
• Power plants
• Oil & gas facilities
• Petrochemical plants
• Industrial condition monitoring systems

Precautions

• Confirm compatibility with the existing Bently Nevada 3500 rack before installation.
• Install the module in the correct rack slot (Slot 1).
• Ensure Ethernet communication settings match the host system configuration.
• Check firmware and configuration software compatibility.
• Avoid installation in areas with excessive vibration, moisture, or electromagnetic interference.
• Disconnect power before removing or replacing the module.
• Configuration should be performed by qualified personnel.
