BENTLY NEVADA 149986-01 3500/33 16-Channel Relay Control Module

Product Overview

The Bently Nevada 149986-01 is a spare 16-channel relay control module for the 3500 Machinery Protection System. It executes programmable alarm-drive and voting logic based on alarm states, equipment status, and measured variables from compatible monitor channels. It is designed to support machinery protection and control functions in industrial monitoring systems.

Key Technical Specifications

• Brand: Bently Nevada

• Model: 149986-01

• Product Series: 3500 Machinery Protection System

• Product Type: 16-Channel Relay Control Module

• Compatible System: 3500/33 16-Channel Relay Module

• Control Capacity: 16 independently programmable relay channels

• Logic Functions: Configurable AND/OR logic and voting logic

• Logic Inputs: Alert, Danger, Not-OK status, and measured variables from compatible monitor channels

• Relay Contact Type: SPDT (single-pole, double-throw), through the compatible relay output module

• Relay Operating Modes: Normally Energized (NE) or Normally De-energized (ND), selectable in four groups of four channels

• Typical Power Consumption: 5.8 W

• Main Module Dimensions (H × W × D): 241 × 24.4 × 242 mm

• Main Module Weight: Approximately 0.7 kg

• Rack Installation: One full-height front slot

• Compatible Rear I/O Module: 149992-01 for standard relay outputs; other variants support failsafe or low-current applications

• Configuration Software: 3500 Rack Configuration Software, version 3.3 or later

Key Features

• Supports 16-channel programmable relay control.

• Allows independent alarm-drive logic configuration for each channel.

• Uses monitor alarm and status information to initiate control actions.

• Provides front-panel OK, TX/RX, and channel alarm indicators.

• Supports normally energized and normally de-energized relay operating modes.

• Integrates with compatible Bently Nevada 3500 monitoring hardware.

Applications

• Turbine and compressor machinery protection

• Industrial vibration monitoring systems

• Alarm and shutdown relay control

• Rotating equipment protection

• Process monitoring and industrial automation

• Maintenance of existing Bently Nevada 3500 systems

Important Notes

• The correct product type is a relay control module, not a signal conditioner.

• Model 149986-01 is the control module; a compatible rear relay output module is required for the complete relay assembly.

• Standard, failsafe, and low-current relay output modules have different specifications and should not be treated as interchangeable without compatibility checks.

• Confirm the installed rack configuration, rear I/O module, contact ratings, and software versions before ordering.

• Verify the exact part number, revision, and product condition before installation or replacement.
