BENTLY NEVADA 176449-02 3500/42M Proximitor/Seismic Monitor

Product Overview

The Bently Nevada 176449-02 is a 3500/42M Proximitor/Seismic Monitor designed for machinery protection and condition monitoring. This four-channel monitor accepts signals from compatible proximity probes and seismic transducers, processes vibration and shaft-position measurements, and compares monitored values against user-configurable alarm setpoints.

Key Technical Specifications

• Brand: Bently Nevada

• Model: 176449-02

• Product Series: 3500

• Product Type: Proximitor/Seismic Monitor Module

• Monitor Model: 3500/42M

• Number of Channels: 4

• Supported Input Signals: Proximity, velocity, and acceleration transducers

• Input Impedance: 10 kΩ for standard proximity and acceleration inputs

• Typical Power Consumption: 7.7 W

• Transducer Power Supply: -24 V DC

• Recorder Outputs: 4–20 mA, proportional to configured monitor full-scale values

• Buffered Transducer Outputs: One coaxial connector per channel

• Configurable Measurement Functions: Radial vibration, thrust position, differential expansion, eccentricity, REBAM, acceleration, velocity, shaft absolute, and circular acceptance region

• Operating Temperature: -30°C to +65°C with compatible standard internal or external termination I/O modules; some barrier configurations have different limits

• Monitor Module Dimensions (H × W × D): 241.3 × 24.4 × 241.8 mm

• Monitor Module Weight: Approximately 0.91 kg

• Installation: Bently Nevada 3500 rack, using a compatible rear I/O module

Key Features

• Four-channel machinery monitoring for vibration and shaft-position measurements.

• Accepts compatible proximity probes and seismic transducers.

• Supports configurable monitoring functions for different machinery conditions.

• Compares measured parameters against programmable alert and danger setpoints.

• Front-panel status LEDs indicate operating condition, communication, and bypass status.

• Provides buffered transducer signals and individual 4–20 mA recorder outputs.

• Designed for integration into the Bently Nevada 3500 machinery protection system.

Applications

• Steam and gas turbine monitoring

• Industrial compressor protection

• Pumps and rotating machinery

• Bearing vibration and shaft displacement monitoring

• Differential expansion and thrust-position monitoring

• Industrial condition monitoring and predictive maintenance

Important Notes

• The correct product designation is Proximitor/Seismic Monitor, rather than a generic interface module.

• This is a monitor card, not a standalone sensor or complete monitoring rack.

• A compatible 3500 rear I/O module and rack installation are required.

• Input type, measurement function, termination hardware, and hazardous-area requirements must be checked against the existing system configuration.

• Verify the complete part number, revision, included hardware, and product condition before ordering.
