B&R 8V1016.00-2 Servo Drive
Item NO.:
8V1016.00-2Payment:
T/TPrice:
$1350Product Origin:
AUSTRIAColor:
NEWProduct weight:
0.09KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The B&R 8V1016.00-2 ACOPOS Servo Drive is a high-performance servo amplifier designed for precise motion control applications. It provides accurate speed, torque, and position control for B&R automation systems and is widely used with B&R ACOPOS motion controllers in industrial automation equipment. The drive features integrated line filter, braking resistor, and electronic restart inhibit functions for reliable operation.
| Parameter | Description |
|---|---|
| Brand | B&R |
| Model | 8V1016.00-2 |
| Product Type | ACOPOS Servo Drive |
| Rated Power | 0.7 kW |
| Continuous Current | 1.6 A RMS |
| Peak Current | 5 A RMS |
| Input Voltage | 3 × 400–480 VAC / 3 × 230 VAC |
| Control Voltage | 24 VDC |
| Frequency | 50/60 Hz |
| Switching Frequency | 5 / 10 / 20 kHz |
| Integrated Functions | Line Filter, Braking Resistor, Safe Restart Inhibit |
| Protection Rating | IP20 |
| Mounting | Control Cabinet Installation |
| Weight | Approx. 2.5 kg |
The structure and details of the product：
