B&R X20DI9371 Digital Input Module
Item NO.:
X20DI9371Payment:
T/TPrice:
$1350Product Origin:
AUSTRIAColor:
NEWProduct weight:
0.09KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The B&R X20DI9371 is a 12-channel Digital Input Module designed for the B&R X20 I/O System. It is used to collect 24 VDC digital signals from field devices such as sensors, switches, limit switches, and proximity detectors, and transmit the input status to the PLC controller for processing.
The module supports 1-wire connection technology and sink input wiring, providing a compact and reliable solution for distributed industrial automation systems.
| Parameter | Specification |
|---|---|
| Manufacturer | B&R Industrial Automation |
| Model | X20DI9371 |
| Product Type | Digital Input Module |
| Series | X20 I/O System |
| Input Channels | 12 Digital Inputs |
| Input Voltage | 24 VDC |
| Input Type | Sink Input |
| Connection Type | 1-wire connection |
| Input Current | Approx. 3.75 mA at 24 VDC |
| Input Filter | Hardware ≤100 μs |
| Software Filter | Configurable 0–25 ms |
| Switching Threshold | Low <5 VDC / High >15 VDC |
| Input Standard | EN 61131-2 Type 1 |
| Isolation | Channel-to-bus isolation |
| Protection Rating | IP20 |
| Power Consumption (Bus) | 0.18 W |
| Internal I/O Power | 1.75 W |
| Mounting | B&R X20 Bus System |
| Required Terminal Block | X20TB12 |
| Required Bus Module | X20BM11 / X20BM15 |
The structure and details of the product：
