B&R 8BAC0120.000-1 Motion Control Module

B&R 8BAC0120.000-1 Motion Control Module (ACOPOSmulti Encoder Interface)





The B&R 8BAC0120.000-1 is a motion control plug-in module used in the B&R ACOPOSmulti servo drive system. It is specifically an EnDat 2.1 encoder interface module, responsible for processing high-precision motor feedback signals.

It is not a standalone controller or PLC, but a servo drive feedback/position measurement module inside a motion system.

Key Specifications

• Model: 8BAC0120.000-1
• Brand: B&R (Bernecker + Rainer)
• System: ACOPOSmulti drive system
• Product Type: Encoder Interface / Motion Control Plug-in Module
• Function:
  • Processes EnDat 2.1 encoder signals
  • Provides high-resolution position feedback
  • Supports motor monitoring and closed-loop control
• Encoder Interface:
  • EnDat 2.1 (high-resolution digital encoder)
• Connection:
  • 15-pin DSUB encoder interface
• Cable length support:
  • Up to ~75 m encoder cable
• Feedback role:
  • Position, speed, and direction feedback for servo control

What it does (simple explanation)

This module acts as the “eyes” of the servo system:

Encoder (motor feedback signal)
↓
8BAC0120 module (signal processing)
↓
ACOPOSmulti drive controller
↓
Motor control adjustment (position/speed/torque)

So it ensures:

• Accurate positioning
• Stable servo control
• High-speed feedback processing

Features & Advantages

• High-precision EnDat 2.1 encoder support
• Very fast signal processing (up to high kHz range)
• Stable differential signal transmission
• Encoder monitoring and fault detection
• Supports long cable runs (industrial machinery scale)
• Plug-in modular design for ACOPOSmulti system
• Enables precise closed-loop servo control

Applications

• CNC machines
• Robotics systems
• High-speed packaging machines
• Printing machines
• Semiconductor equipment
• Multi-axis motion control systems
