B&R 5AP1120.101E-F05 Operator Panel

B&R 5AP1120.101E-F05

Automation Panel 1000 (Operator Panel)

Specifications

• Display: 10.1" TFT color LCD, WXGA 1280 × 800 pixels (16:10)
• Touch: Analog resistive single-touch
• Backlight: LED, dimmable (25–1000 cd/m², rev. E0)
• Front Protection: IP65 / UL Type 4X (aluminum frame)
• Power: 24 VDC ±10%
• Interfaces: USB 2.0, RS-232, Ethernet (via link module)
• Operating Temp: -20 °C to +50 °C
• Mounting: Control cabinet, landscape flush mount
• Dimensions (W×H×D): ~275 × 175 × 50 mm
• Weight: ~1.2 kg
• Certifications: CE, UL, cULus, HazLoc, RoHS

Key Features

• High-Resolution Display: 10.1" WXGA for sharp visualization
• Industrial-Grade Touch: Resistive touch works with gloves, dust/moisture resistant
• Robust Front Panel: IP65/Type 4X for harsh industrial environments
• Flexible Integration: Compatible with B&R PPC2100/PPC3x00/PPC2200 and link modules
• F05 Variant: Includes protective film and enhanced touch durability
