B&R 4PP420.1043.75 Touch Panel

B&R 4PP420.1043.75

Basic Information

• Manufacturer: B&R (Bernecker + Rainer, ABB Group)
• Model: 4PP420.1043.75 (also written as 4PP420.1043-75)
• Series: Power Panel 400 (PP420)
• Type: All‑in‑one HMI + industrial controller, resistive touch
• Application: Machine control, visualization, embedded automation




Specifications

• Display: 10.4" TFT LCD, VGA 640×480 pixels, 256K colors
• Touchscreen: 4‑wire resistive, single‑touch, glove‑compatible
• Processor: Integrated (PP420 series)
• Memory: 128 MB SDRAM, 512 KB SRAM
• Storage: CompactFlash slot (Type I)
• Expansion: 1 × aPCI slot
• Interfaces:
  • Ethernet 10/100 Mbps
  • RS232
  • 2 × USB 2.0
• Protection: Front IP65 / UL Type 4X, dust‑tight and splash‑proof
• Power: 24 VDC (18–30 VDC), ~0.71 A, 17 W
• Operating Temp: 0 °C to +50 °C; storage −20 °C to +70 °C
• Dimensions: W 248 mm × H 186 mm × D 53 mm
• Weight: ~3.6 kg
• Certifications: CE, cULus, RoHS

Key Features

• Integrated HMI + PLC: no separate IPC needed
• Robust resistive touch: works with gloves, resistant to oil/dust
• IP65 front panel: ideal for harsh factory environments
• Rich I/O & expansion: Ethernet, serial, USB, aPCI slot
• Compact panel mount: fits standard control cabinet cutouts
