B&R 5AP1120.101E-F05 Operator Panel

B&R 5AP1120.101E-F05

Basic Information

• Manufacturer: B&R (Bernecker + Rainer, ABB Group)
• Model: 5AP1120.101E-F05
• Series: Automation Panel 1000 (AP1000)
• Type: Cabinet-mount operator panel (HMI), single-touch resistive
• Application: Machine visualization, process control, industrial automation

Specifications

• Display: 10.1" TFT LCD, WXGA 1280×800 pixels (16:10), 16.7M colors
• Backlight: LED, dimmable 25–500 cd/m² (F0 revision), 50,000 hrs half-brightnessB& R Industrial Automation
• Touchscreen: Analog resistive, single-touch, 12-bit controllerB& R Industrial Automation
• Protection: Front IP65 / UL Type 4X; coated aluminum front (RAL7024)
• Mounting: Landscape, flush control cabinet install
• Power: 24 VDC (±10%), typical ~15 W
• Interfaces: USB 2.0, RS232, SDL/DVI (for PPC2100/PPC3x00)
• Operating Temp: 0 °C to +50 °C; storage −20 °C to +50 °C
• Dimensions: W 279 mm × H 191 mm × D 52 mm
• Weight: ~2.8 kg
• Certifications: CE, cULus, HazLoc (Class 2, Zone 2), RoHS

Key Features

• High-resolution 10.1" WXGA display for sharp visualization
• Industrial resistive touch, reliable in harsh conditions (gloves usable)
• IP65 front panel for dust/water resistance
• LED backlight with long service life and low power consumption
• Seamless integration with B&R PPC2100/PPC3x00 industrial PCs
