Phoenix MCR-PS-24DC-10DC Power Supply Converter

Phoenix Contact MCR‑PS‑24DC‑10DC

DC/DC Power Supply Converter (Isolated, 24V→10V)

Specifications

• Input: 18–30 V DC (nominal 24 V DC)
• Output: 10 V DC ±0.1% (precision reference)
• Output Current: 30 mA (continuous), short‑circuit current ~65 mA
• Isolation: Galvanic isolation (input/output)
• Residual Ripple: ≤50 mVpp
• Temperature Coefficient: ≤0.015 %/K
• Connection: Pluggable screw terminals (0.2–2.5 mm² / AWG 24–14)
• Mounting: 35 mm DIN rail
• Dimensions: 12.5 mm (W) × 99 mm (H) × 114.5 mm (D)
• Operating Temp: −20°C to +65°C
• Certifications: CE
• Weight: ~70 g

Key Features

• Precision 10V Reference: ±0.1% accuracy, ideal for sensor/PLC analog circuits
• Galvanic Isolation: Breaks ground loops, improves noise immunity
• Compact & Slim: 12.5 mm width, saves DIN rail space
• Wide Input Range: 18–30 V DC, fits standard 24 V industrial systems
• Protections: Overload, short‑circuit, reverse polarity
• High Reliability: Industrial temperature range, low drift

Applications

• Analog Sensor Power: Precision 10 V supply for pressure, temperature, and strain sensors
• PLC & DCS Reference: Stable 10 V reference for analog input modules
• Signal Conditioning: Isolated power for MCR signal conditioners
• Industrial Automation: Panel‑mounted distributed power
