B&R 4PP220.1505-K03 Operator Panel

Product Description

B&R 4PP220.1505-K03 is a Power Panel 200 Industrial Operator Panel / HMI Controller from B&R Industrial Automation. It combines a 15-inch color TFT touch display with embedded automation control functions, providing an integrated solution for machine operation, visualization, and industrial control applications.

The unit is designed for machine builders requiring a compact HMI interface with PLC functionality, communication interfaces, and industrial-grade protection.

Specifications

• Brand: B&R Industrial Automation
• Model: 4PP220.1505-K03
• Product Type: Industrial Operator Panel / HMI Controller
• Series: Power Panel 200 (PP220)
• Display Size: 15 inch
• Display Type: Color TFT LCD
• Resolution: XGA 1024 × 768 pixels
• Touch Type: Resistive Touch Screen
• Power Supply: 24 VDC
• Protection Rating: IP65 (front panel)
• Housing: Industrial metal housing
• Mounting: Panel mounting
• Communication Interfaces:
  • Ethernet 10/100
  • RS232
  • 2 × USB
• Memory:
  • 64 MB SDRAM
  • 256 kB SRAM
  • CompactFlash Type I slot
• Expansion: 1 × aPCI slot
• Battery Backup: Integrated battery support
• Display Orientation: Vertical mounting

Functions

• Provides operator-machine interaction interface
• Displays machine status, alarms, and process data
• Runs B&R Automation Runtime applications
• Performs PLC control and visualization tasks
• Communicates with PLC systems, I/O modules, and industrial networks
• Stores application programs through CompactFlash memory

Advantages & Features

• Integrated HMI and controller design
• Large 15-inch industrial touchscreen display
• High-resolution XGA visualization
• Rugged metal housing for industrial environments
• Front IP65 protection suitable for machine installation
• Supports Ethernet and serial communication
• Compact solution combining operation and control functions

Applications

• Industrial machine control
• Production line monitoring
• Packaging machinery
• CNC equipment
• Factory automation systems
• Process visualization systems
• B&R automation platforms

Notes

• 4PP220.1505-K03 is an industrial HMI/operator panel, not a simple display
• Requires compatible B&R Automation Studio software environment
• Verify CompactFlash/application program compatibility before replacement
• Check 24VDC power supply and terminal connection before installation
• Touchscreen and display components should be protected from mechanical impact
