B&R 8EI017HWDS0.0300-1 Servo Drive Module

Product Overview

Model: 8EI017HWDS0.0300-1
Series: ACOPOS P3 Servo Drive
Manufacturer: B&R Industrial Automation

The B&R 8EI017HWDS0.0300-1 is an ACOPOS P3 two-axis servo drive module designed for high-performance motion control applications. It provides precise servo motor control, integrated safety functions, and fast POWERLINK communication for advanced industrial automation systems.

Technical Specifications

• Product Type: Servo Drive Module
• Model: 8EI017HWDS0.0300-1
• Series: B&R ACOPOS P3
• Axis Configuration: Dual-axis servo drive
• Motor Axes: 2 axes
• Rated Output Current: 17 A per axis
• Continuous Motor Power: 7 kW per motor connection
• Peak Output Current: 42.5 A per axis
• Input Voltage: 3 × 200–480 VAC ±10%
• Frequency: 50/60 Hz
• Installed Load: Max. 26.4 kVA
• DC Bus Continuous Power: 14 kW
• Communication Interface: POWERLINK V2
• Communication Speed: 100 Mbit/s
• Encoder Interfaces: 2 × configurable digital multi-encoder interfaces
• Safety Function: SafeMOTION (SIL 2 / PL d)
• Braking Resistor Output: Supported
• Protection Class: IP20
• Mounting: Wall mounting / control cabinet installation
• Dimensions: Approx. 374 × 133 × 258.5 mm
• Weight: Approx. 8 kg

Advantages & Features

• High-Performance Motion Control
  Provides accurate speed, torque, and position control for demanding automation applications.
• Dual-Axis Compact Design
  Controls two servo motors in one module, reducing cabinet space and wiring requirements.
• Fast POWERLINK Communication
  Enables high-speed and deterministic communication with B&R PLC systems.
• Integrated Safety Technology
  Supports SafeMOTION safety functions to improve machine safety performance.
• High Dynamic Response
  Suitable for applications requiring rapid acceleration, deceleration, and precise positioning.
• Reliable Industrial Design
  Designed for continuous operation in advanced manufacturing environments.

Applications

• Industrial Automation Equipment
• Robotics Systems
• Packaging Machinery
• CNC Machines
• Semiconductor Manufacturing Equipment
• Printing Machinery
• High-Speed Production Lines
• Precision Motion Control Systems

Precautions

• Verify input voltage and power requirements before installation.
• Confirm compatibility between servo drive and motor model.
• Check POWERLINK network configuration before commissioning.
• Ensure encoder wiring and feedback settings are correct.
• Verify safety function wiring before operation.
• Provide sufficient cabinet ventilation and cooling.
• Perform parameter configuration and motor tuning after replacement.
