B&R 4PP065.0571-X74F Panel PC

Product Description

B&R 4PP065.0571-X74F is a Power Panel 65 (PP65) Industrial Panel PC / HMI Controller from B&R Industrial Automation. It combines a 5.7-inch color TFT touch display, embedded controller, PLC runtime capability, and communication interfaces in a compact industrial operator panel.

The unit is designed for machine control, visualization, and operator interface applications, supporting B&R Automation Runtime for PLC-based automation tasks.

Specifications

• Brand: B&R Industrial Automation
• Model: 4PP065.0571-X74F
• Product Type: Industrial Panel PC / HMI Controller
• Series: Power Panel 65 (PP65)
• Display Type: 5.7" TFT Color Display
• Resolution: QVGA 320 × 240 pixels
• Touch Screen: Resistive Touch (12-bit controller)
• Function Keys: 10 membrane function keys
• Processor: AMD Geode LX800, 32-bit x86
• Processor Speed: 500 MHz
• RAM: 128 MB DDR SDRAM
• User SRAM: 232 kB
• Flash Memory: 4 MB firmware storage
• Cooling: Passive cooling with heat sink
• Power Supply: 24 VDC ±25%
• Power Consumption: Approx. 10 W
• Communication Interfaces:
  • 1 × Ethernet 10/100BASE-T
  • 1 × X2X Link
  • 2 × USB 2.0
  • 1 × CompactFlash Slot
• Protection Rating:
  • Front panel: IP65 / NEMA 250 Type 4X
  • Rear: IP20
• Dimensions: 203 × 145 × 56.5 mm
• Weight: Approx. 0.75 kg

Functions

• Provides industrial machine operator interface
• Runs B&R Automation Runtime applications
• Displays production data, alarms, and machine status
• Performs PLC control and visualization functions
• Communicates with PLC, I/O modules, and industrial networks
• Supports CompactFlash-based application storage

Advantages & Features

• Integrated HMI and controller design
• Compact size for machine installation
• Resistive touchscreen suitable for industrial environments
• Supports PLC and visualization tasks in one device
• Fanless passive cooling improves reliability
• IP65 front protection for harsh environments
• Multiple industrial communication interfaces

Applications

• Machine automation systems
• Packaging equipment
• CNC and production machines
• Factory automation lines
• Process monitoring systems
• Industrial operator stations
• B&R PLC control applications

Notes

• 4PP065.0571-X74F is an industrial Panel PC/HMI controller, not a simple display panel
• Requires compatible B&R software environment (Automation Runtime)
• Application memory/CompactFlash card may need to be ordered separately
• Terminal blocks (0TB103 / 0TB704) are separate accessories
• Contains a removable 3V 950mAh lithium battery for backup functions, with typical service life around 4 years
