Allen-Bradley 1769-OW16 CompactLogix Relay Output Module

Product Description

The 1769-OW16 is a 16-point relay output module designed for Allen-Bradley CompactLogix and MicroLogix 1500 control systems. It provides isolated relay contacts for switching AC/DC loads, making it suitable for controlling motors, solenoids, and other industrial devices .

Key Features

Relay Output Configuration
- 16 Form A (normally open) relay contacts .
- Supports 5–240V DC or 5–250V AC load switching .
High Load Capacity
- 3A per point (resistive load) @ 250V AC / 30V DC .
- 16A max per module (derating required for inductive loads) .
Isolation & Protection
- 1,500V AC channel-to-channel isolation .
- LED status indicators for per-point diagnostics .
Compact & Modular Design
- Single-slot width (35mm) for space efficiency .
- DIN rail or panel mounting .
Compatibility
- Works with CompactLogix L3x, MicroLogix 1500, and Compact GuardLogix .

Technical Specifications

Parameter	Value
Model	1769-OW16
Output Type	16 relay contacts (NO)
Load Voltage	5–250V AC / 5–240V DC
Max Current	3A per point (resistive)
Switching Frequency	≤1 Hz (inductive loads)
Isolation Voltage	1,500V AC
Operating Temp.	0°C to +60°C
Dimensions	118 × 35 × 87 mm
Weight	~0.61 kg

Applications

Motor Starters (contactor control) .
HVAC Systems (fan/pump relays) .
Packaging Machines (actuator control) .

Installation & Usage Notes

Wiring
- Use shielded cables for noise immunity .
- Ensure proper fusing for inductive loads .
Maintenance
- Monitor relay lifespan (mechanical: 10M cycles / electrical: 100K cycles) .
Configuration
- Program via Studio 5000 or RSLogix 5000 .
