Allen-Bradley 100-FPTB30 Contactor Terminal Block

Allen-Bradley 100-FPTB30 Contactor Terminal Block / Timing Module

Product Overview

The Allen-Bradley 100-FPTB30 is not a contactor terminal block. It is a Bulletin 100-C Pneumatic Timing Module (OFF-Delay Timer) from Rockwell Automation, used as an accessory for Allen-Bradley IEC contactors and control relays. It provides an adjustable time delay after the contactor coil is de-energized.

This accessory is designed for use with 100-C series contactors and 700-CF series control relays to add timing functions to motor control and automation circuits.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 100-FPTB30
• Product Type:
  • Pneumatic Timing Module
  • Contactor Timer Accessory
• Series:
  • Bulletin 100-C / MCS Series

Timing Function

• Timer Type:
  • OFF-Delay Timer
• Timing Range:
  • 0.3 to 30 seconds
• Adjustment:
  • Adjustable time delay
• Frequency:
  • 50/60 Hz

Compatibility

• Compatible Contactors:
  • Allen-Bradley 100-C Series IEC Contactors
• Compatible Relays:
  • 700-CF Series Control Relays
• Mounting:
  • Front mounting accessory

Contact Configuration

• Contact Type:
  • Timing auxiliary contacts
• Operation:
  • Delayed switching after coil de-energization

Advantages & Features

• Adds OFF-delay timing function to standard contactors
• Adjustable delay range from 0.3–30 seconds
• Improves control sequence flexibility
• Reduces need for separate timer relays
• Compact accessory design for IEC contactors
• Easy installation on compatible Allen-Bradley devices
• Suitable for industrial motor control applications

Applications

• Motor starter control circuits
• Conveyor systems
• Pump control systems
• Fan and blower delay circuits
• Industrial automation sequences
• Machine control panels
• PLC output timing extension

Important Notes

• 100-FPTB30 is a timer accessory, not a terminal block.
• Verify compatibility with the installed contactor model before use.
• Confirm required timing function (ON-delay or OFF-delay).
• Do not exceed the rated contact load.
• Disconnect power before installation or replacement.
