Allen-Bradley 100-FPTB180 Contactor Terminal Block

Allen-Bradley 100-FPTB180 Contactor Terminal Block / Timing Module

Product Overview

The Allen-Bradley 100-FPTB180 is not a contactor terminal block. It is a Bulletin 100-C Pneumatic Timing Module (OFF-Delay Timer) from Rockwell Automation, designed as an accessory for Allen-Bradley IEC contactors and control relays. It provides a time delay function after the contactor coil is de-energized.

The module uses pneumatic timing technology and is installed on compatible 100-C series contactors, 104-C contactors, and 700-CF / 700S-CF control relays to add OFF-delay control functions.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 100-FPTB180
• Product Type:
  • Pneumatic Timing Module
  • Contactor Timer Accessory
• Series:
  • Bulletin 100-C / MCS

Timing Function

• Timer Type:
  • OFF-Delay Timer
• Timing Range:
  • 1.8–180 seconds
• Adjustment:
  • Adjustable delay setting
• Frequency:
  • 50/60 Hz

Compatibility

• Compatible Contactors:
  • Allen-Bradley 100-C Series IEC Contactors
  • 104-C Series Contactors
• Compatible Control Relays:
  • 700-CF Series
  • 700S-CF Series
• Mounting:
  • Front-mounted accessory

Contact Configuration

• Contact Type:
  • Timing auxiliary contacts
• Contact Arrangement:
  • 1NO + 1NC
• Function:
  • Contacts change state after the preset OFF-delay time

Advantages & Features

• Adds OFF-delay timing capability to standard contactors
• Adjustable delay range up to 180 seconds
• Eliminates the need for separate external timer relays
• Compact design for IEC contactor systems
• Improves control sequence flexibility
• Suitable for motor control and automation circuits
• Reliable pneumatic timing operation

Applications

• Motor starter control circuits
• Conveyor systems
• Pump shutdown delay control
• Fan and blower control
• Industrial automation panels
• Machine sequencing systems
• PLC output timing extension
