ABB TK817F (3BDM000356R1) CAN Cable

1. Key Parameters

• Product Model: TK817F
• Order Code: 3BDM000356R1
• Product Series: ABB TK Series Industrial CAN Cables (CANopen/CAN 2.0B, Compatible with ABB AC500/ACS Automation Devices)
• Core Function: Transmits CANopen/CAN 2.0B data between ABB automation nodes (PLCs, drives, I/O); minimizes EMI/RFI interference; maintains bus termination and signal integrity; provides mechanical protection against industrial wear
• Electrical Specifications:

  Parameter	Details	Performance Metrics
  CAN Bus Performance	- Supported Protocols: CANopen, CAN 2.0B (high-speed CAN, 1Mbps) - Maximum Data Rate: 1Mbps (up to 40m); 500kbps (up to 100m); 125kbps (up to 500m) - Signal Attenuation: ≤0.2dB/m (at 1MHz) - Bus Termination: 120Ω ±10% (integrated, selectable via DIP switch)	Enables real-time machine control (≤1ms latency) for multi-node systems (e.g., conveyor lines with 10+ drives)
  Conductor Configuration	- Conductor Material: Tinned copper (corrosion-resistant, low resistance) - Conductor Structure: 2× twisted pairs (CAN_H/CAN_L + auxiliary power); 24 AWG (0.22mm²) per conductor - Twist Rate: 12mm~16mm (CAN pair); 18mm~22mm (power pair) - Conductor Resistance: ≤85Ω/km (at 20℃)	Twisted CAN pair reduces crosstalk by 50% vs. non-twisted cables; tinned copper ensures stable signal transmission over 500m+ distances
  Insulation & Shielding	- Insulation Material: Cross-linked polyethylene (XLPE, heat-resistant) - Shielding: Dual-layer (aluminum foil + tinned copper braid, 90% coverage) - Outer Sheath: Halogen-free flame-retardant (HFFR) PVC; thickness 0.9mm~1.1mm - Dielectric Constant (εr): ≤2.4 (at 1MHz)	Dual shielding blocks 98% of EMI/RFI (e.g., from motor drives, inverters); XLPE insulation resists thermal aging, extending service life to 15+ years
  Safety & Compliance	- Insulation Resistance: ≥100MΩ (at 500V DC, 20℃) - Flame Class: UL 94 V0 / IEC 60332-1-2 (self-extinguishing within 10s) - Voltage Withstand: 1500V AC (1min, conductor to shield) - Crosstalk: ≤-50dB (at 1MHz, CAN pair to power pair)	Prevents signal leakage and fire propagation; low crosstalk ensures no interference between CAN data and auxiliary power lines

• Mechanical Specifications:
  • Cable Diameter: 5.5mm~6.5mm (outer diameter)
  • Standard Length: 10m (custom lengths: 1m~100m available via ABB customization)
  • Connector Type:
    • Equipment End: ABB proprietary 4-pin M12 male connectors (IP67, for AC500 PLCs/ACS drives) with locking thread
    • Termination End: Terminal block (for bus termination, 120Ω) or 4-pin M12 female connector (for daisy-chaining nodes)
  • Connector Material:
    • Housing: Polyamide 66 (PA66, impact-resistant, heat-resistant up to 120℃)
    • Contacts: Brass (gold-plated, low contact resistance ≤5mΩ)
  • Mechanical Durability:
    • Flex Life: ≥8,000 cycles (IEC 60245, 8× cable diameter bending radius)
    • Impact Resistance: IK07 (IEC 62262, resistant to 2J impacts)
    • Abrasion Resistance: ≥1,500 cycles (CS 10 wheel, 10N load)
  • Weight: Approximately 0.3kg/m (for 10m length)
• Environmental Ratings:
  • Operating Temperature Range: -40℃~+80℃ (-40℉~176℉)
  • Storage Temperature Range: -50℃~+85℃ (-58℉~185℉)
  • Humidity Tolerance: 5%~95% RH (non-condensing, 40℃)
  • Chemical Resistance: Resistant to mineral oil, grease, and dilute acids/bases (per IEC 60068-2-54)
  • Ingress Protection (IP): IP20 (cable sheath); IP67 (with M12 connectors)
  • Vibration Resistance: 10~500Hz, 2g acceleration (IEC 60068-2-6; no signal loss or bus errors)
• Compliance Standards: ISO 11898-2 (high-speed CAN), IEC 60245-5 (flexible industrial cables), UL 444 (communication cables), CE, RoHS, GB/T 18287 (China industrial CAN cables)

2. Key Features

• CANopen/CAN 2.0B Optimization: Tailored for ABB’s CAN-based automation systems—supports data rates up to 1Mbps and node counts up to 32, enabling seamless integration with AC500 PLCs, ACS drives, and distributed I/O (e.g., AI531 analog input modules).
• Integrated Bus Termination: Built-in 120Ω selectable termination (via DIP switch) eliminates the need for external terminators—simplifies bus setup (critical for daisy-chained networks like conveyor lines) and ensures consistent signal integrity across all nodes.
• Dual-Layer EMI Shielding: Aluminum foil + 90% copper braid shielding blocks electromagnetic interference from industrial equipment (e.g., welders, large motors)—prevents CAN bus errors (e.g., "bit stuffing errors," "arbitration loss") that cause machine downtime.
• Halogen-Free Flame Retardancy: HFFR PVC sheath emits minimal smoke and toxic gas in fire—complies with safety standards for enclosed industrial spaces (e.g., automotive paint shops, food processing cleanrooms) and public infrastructure.
• IP67 M12 Connectors: Gold-plated M12 connectors with IP67 rating ensure dust-tight and water-jet-resistant connections—suitable for semi-outdoor or damp environments (e.g., washdown areas in beverage plants, outdoor conveyor systems).
• Wide Temperature & Vibration Resistance: -40℃~+80℃ operating range and 2g vibration tolerance—operates reliably in extreme conditions (e.g., cold storage facilities, high-vibration mining equipment) without performance degradation.
• Auxiliary Power Pair: Integrated 2-wire power pair (24V DC, 0.5A max) eliminates the need for separate power cables—powers low-consumption nodes (e.g., small I/O modules) while transmitting CAN data, reducing wiring complexity in machine cabinets.

3. Application Fields

• ABB CAN-Based Automation Networks: Primary application—connecting ABB CANopen/CAN 2.0B devices:
  • Conveyor Line Control Systems: Links AC500 PLCs to 10+ ACS355 drives (conveyor motors) via CANopen; 1Mbps data rate enables synchronized speed control (±0.1m/s) to prevent package jams, while integrated termination simplifies bus setup.
  • Machine Tool I/O Networks: Connects AC500 PLCs to distributed I/O modules (e.g., DI531 digital input) on CNC machines; dual shielding resists EMI from spindle motors, ensuring accurate transmission of limit switch and sensor signals.
• Automotive Manufacturing: CAN bus communication for production equipment:
  • Paint Shop Robotics: Connects ABB robotic controllers to ACS drives and spray gun I/O modules via CANopen; HFFR sheath complies with paint shop fire codes, while IP67 connectors resist solvent vapors and washdowns.
  • Assembly Line Material Handling: Transmits CAN data between AC500 PLCs and AGV (Automated Guided Vehicle) controllers; 500m range (125kbps) covers large factory floors, and auxiliary power pair powers AGV position sensors.
• Food & Beverage Processing: Hygienic and reliable communication:
  • Bottling Plant Fillers: Connects AC500 PLCs to ACS150 drives (filler motors) and level sensor I/O modules; IP67 M12 connectors withstand daily washdowns (100bar water jets), while HFFR sheath is easy to clean and decontaminate.
  • Dairy Processing Lines: Links AC500 PLCs to temperature control I/O modules and small pumps via CANopen; -40℃ low-temperature rating works in cold storage auxiliary lines, ensuring stable data transmission for refrigeration control.
• Mining & Heavy Machinery: CAN bus for rugged environments:
  • Underground Mining Conveyors: Connects surface AC500 PLCs to underground ACS800 drives (conveyor motors) via CAN 2.0B; dual shielding resists EMI from mining crushers, while 2g vibration tolerance handles conveyor motion.
  • Construction Equipment Control: Transmits CAN data between AC500-based controllers and hydraulic valve I/O modules on excavators; IP67 connectors protect against dust and rain, and wide temperature range (-40℃~+80℃) handles outdoor weather extremes.
• Building Automation & HVAC: CAN communication for smart buildings:
  • HVAC Zone Control: Links central AC500 PLCs to room temperature sensors and fan coil drives via CANopen; auxiliary power pair powers sensors, reducing wiring in ceiling voids, while low crosstalk ensures no interference with other building networks.
  • Elevator Control Systems: Connects elevator AC500 controllers to door drives and position encoders via CAN 2.0B; 1Mbps data rate enables precise floor alignment (±2mm), and flame-retardant sheath complies with elevator safety standards.

The structure and details of the product：
