ABB TK831F (3BDM000100R1) Communication Cable

1. Key Parameters

• Product Model: TK831F
• Order Code: 3BDM000100R1
• Product Series: ABB TK Series Industrial Communication Cables (High-Bandwidth, Compatible with 800xA/AC800M Ecosystems)
• Core Function: Transmits high-speed data between ABB 800xA DCS, AC800M PLCs, and remote I/O devices; provides robust EMI/RFI immunity; supports ABB proprietary protocols and standard industrial Ethernet; ensures signal integrity over extended distances
• Electrical Specifications:

  Parameter	Details	Performance Metrics
  Communication Performance	- Supported Protocols: ABB S800 I/O Bus, PROFINET IRT, EtherCAT (1Gbps) - Maximum Data Rate: 1Gbps (full-duplex) - Signal Attenuation: ≤0.3dB/m (at 500MHz) - Delay Skew: ≤5ns (between pairs)	Enables real-time control with ≤500ns latency, critical for synchronized multi-axis systems (e.g., robotic assembly lines)
  Conductor Configuration	- Conductor Material: Oxygen-free copper (OFC, high conductivity) - Conductor Structure: 4× twisted pairs (Cat6A); 23 AWG (0.25mm²) per conductor - Twist Rate: Variable (10mm~20mm) with pair-to-pair differential twisting - Characteristic Impedance: 100Ω ±20Ω (at 1~500MHz)	Oxygen-free copper minimizes signal loss; differential twisting reduces crosstalk by 70% vs. Cat5e cables
  Insulation & Shielding	- Insulation Material: Foam polyethylene (Foam PE, low dielectric constant) - Shielding: Foil-shielded twisted pairs (FTP) + overall braided shield (95% coverage) - Outer Sheath: Halogen-free flame-retardant (HFFR) polyurethane (PU) - Dielectric Strength: 2000V AC (1min, conductor to shield)	Multi-layer shielding blocks 99.9% of EMI/RFI; HFFR PU sheath resists oil, chemicals, and abrasion
  Safety & Compliance	- Insulation Resistance: ≥100MΩ (at 500V DC, 20℃) - Flame Class: UL 94 V0 / IEC 60332-1-2 (self-extinguishing within 5s) - Smoke Density: ≤50% (IEC 61034-2) - Toxicity Index: ≤5 (IEC 60754-2)	Low smoke and toxicity emission enhances safety in enclosed spaces; high flame resistance meets critical infrastructure standards

• Mechanical Specifications:
  • Cable Diameter: 8.0mm~9.0mm (outer diameter)
  • Standard Length: 50m (custom lengths: 1m~300m available via ABB customization)
  • Connector Compatibility: ABB M12 X-coded (for 800xA I/O modules), RJ45 (for Ethernet switches); compatible with ABB S800 I/O bus connectors
  • Mechanical Durability:
    • Flex Life: ≥3,000 cycles (IEC 60245, 12× cable diameter bending radius)
    • Impact Resistance: IK08 (IEC 62262, 5J impact resistance)
    • Abrasion Resistance: ≥2,000 cycles (CS 10 wheel, 10N load)
  • Weight: Approximately 0.8kg/m (for 50m length)
• Environmental Ratings:
  • Operating Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Storage Temperature Range: -50℃~+90℃ (-58℉~194℉)
  • Humidity Tolerance: 5%~95% RH (non-condensing, 40℃)
  • Chemical Resistance: Resistant to mineral oil, hydraulic fluids, dilute acids, and alkalis (per IEC 60068-2-54)
  • Ingress Protection (IP): IP2X (cable sheath); IP67 (with M12 connectors)
  • Vibration Resistance: 10~500Hz, 2g acceleration (IEC 60068-2-6; no signal degradation)
• Compliance Standards: IEC 61156-6 (Cat6A cables), EN 50173-1 (industrial communication), UL 444 (communication cables), CE, RoHS, GB/T 18287 (China)

2. Key Features

• 1Gbps High-Speed Transmission: Supports 1Gbps full-duplex data rates with ≤500ns latency—enables real-time synchronization of ABB 800xA DCS and AC800M PLCs in time-critical applications (e.g., chemical reactor control, high-speed packaging lines).
• Advanced Multi-Layer Shielding: Foil-shielded twisted pairs (FTP) plus 95% coverage overall braid—provides exceptional EMI/RFI immunity, ensuring reliable communication near high-power equipment (e.g., arc furnaces, large motor drives) where electromagnetic noise is severe.
• Cat6A Performance: Exceeds Cat6A specifications with ≤0.3dB/m attenuation and ≤5ns delay skew—maintains signal integrity over 300m+ distances, eliminating the need for signal repeaters in large-scale facilities (e.g., automotive plants, refineries).
• Halogen-Free Flame Retardancy: HFFR polyurethane sheath emits minimal smoke and toxic gas during combustion—complies with safety standards for critical infrastructure (e.g., nuclear power plants, offshore platforms) where fire safety is paramount.
• Oil & Chemical Resistance: PU sheath resists mineral oil, hydraulic fluids, and dilute chemicals—ideal for harsh industrial environments (e.g., steel mills, chemical processing plants) where exposure to industrial fluids is common.
• ABB Ecosystem Optimization: Tailored for ABB 800xA DCS, AC800M PLCs, and S800 I/O modules—ensures seamless integration with ABB's proprietary communication protocols, maximizing network performance and minimizing compatibility issues.
• Wide Temperature Range: Operates reliably from -40℃ to +85℃—performs in extreme environments, including arctic oil fields, desert solar plants, and high-temperature industrial zones (e.g., near furnaces).

3. Application Fields

• ABB 800xA/AC800M Automation Networks: Primary application—high-speed data backbone for ABB's advanced control systems:
  • Refinery DCS Systems: Connects 800xA operator stations to AC800M controllers in crude oil distillation units; 1Gbps bandwidth enables simultaneous transmission of 1000+ process variables (temperature, pressure, flow), ensuring precise process control.
  • Automotive Body Shops: Links AC800M PLCs to S800 remote I/O modules controlling robotic welders; PROFINET IRT support ensures ≤1ms synchronization between robots, maintaining ±0.5mm precision in vehicle body assembly.
• Heavy Industry Control Systems: High-reliability communication in harsh environments:
  • Steel Mill Rolling Lines: Transmits data between 800xA DCS and AC800M PLCs controlling hot rolling mills; oil-resistant PU sheath withstands contact with hydraulic fluids, while multi-layer shielding resists EMI from rolling mill motors.
  • Mining Processing Plants: Connects remote I/O modules (monitoring ore crushers) to central 800xA DCS; -40℃ low-temperature rating and 2g vibration resistance ensure reliable operation in cold, high-vibration mining environments.
• Energy & Utility Infrastructure: Critical data transmission for energy systems:
  • Nuclear Power Plant Control Networks: Links safety-critical I/O modules to 800xA DCS in non-radiation zones; low smoke/toxicity emission meets nuclear safety standards, while 2000V dielectric strength prevents signal interference.
  • Offshore Wind Farms: Connects wind turbine controllers to offshore 800xA SCADA systems; halogen-free sheath and chemical resistance withstand saltwater spray and harsh marine conditions, ensuring 99.99% network availability.
• Pharmaceutical & Food Processing: High-purity communication in hygienic environments:
  • Biopharmaceutical Production Lines: Transmits data between AC800M PLCs and cleanroom I/O modules; smooth PU sheath is easy to clean and decontaminate, complying with FDA and GMP standards for hygienic production.
  • Beverage Bottling Plants: Connects 800xA DCS to high-speed filling machine controllers; 1Gbps data rate enables real-time adjustment of filling parameters based on bottle position feedback, reducing waste by 15%.

The structure and details of the product：
