ABB SXBU-710 Resistor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

 1. Product Overview

The ABB SXBU-710 Resistor is a key component in industrial automation and power electronics, used for current limiting, voltage division, power absorption, and circuit protection. It is made of high-quality materials, offering stable resistance, high temperature tolerance, vibration resistance, and long service life. It provides reliable performance in industrial environments and is widely used in drive modules, controllers, and power devices.

2. Main Technical Parameters (Typical)

Electrical Data

• Model: SXBU-710

• Resistance: Varies by model (commonly tens to thousands of ohms)

• Power rating: 10–50 W (depending on model)

• Tolerance: ±1% or ±5%

• Temperature coefficient: ±100 ppm/°C (typical)

• Insulation resistance: >10^9 Ω

• Voltage withstand: AC 500–1000 V (typical)

• Operating voltage: According to resistance and power rating

Mechanical & Installation

• Package type: Power-type fixed resistor with metal or ceramic housing

• Mounting: Bolt-fixed or PCB soldering

• Dimensions: Based on power rating

• Weight: approx. 0.05–0.2 kg

Environmental & Operating Conditions

• Operating temperature: ‑40°C to +155°C

• Storage temperature: ‑55°C to +160°C

• Relative humidity: 5%–95% (non-condensing)

• Vibration and shock resistant: Industrial-grade design

• Protection level: Optional IP20–IP50

Standards & Certifications

• IEC 60115 series standards

• RoHS certified

3. Advantages and Features

• High reliability: High-quality materials, stable resistance, long lifespan

• High temperature & vibration resistance: Suitable for harsh industrial environments

• Variety of power and resistance options: Meets different circuit requirements

• Good protection: Metal or ceramic housing, resistant to moisture and dust

• Easy installation & maintenance: Supports bolt fixation or PCB soldering

• Wide application: For power absorption, current limiting, voltage division, and protection circuits

4. Typical Applications

• Industrial automation drive modules

• Power electronics devices and controllers

• PLC, motor control, and power regulation equipment

• Power supply modules and voltage/current limiting circuits

• Industrial robots and automated production lines

5. Application Notes

• Select appropriate resistance and power rating according to circuit voltage, current, and power

• Ensure proper heat dissipation during installation

• Avoid long-term overload operation

• Secure mounting to prevent loosening due to vibration

• Avoid direct exposure to corrosive gases or liquids

• Regularly inspect for visual damage or resistance drift

The structure and details of the product：
