ABB FPX-66-9177-B Analog Output Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

 1. Product Overview

The ABB FPX-66-9177-B Analog Output Module is a key component in ABB industrial automation and process control systems. It converts digital control signals into analog voltage or current outputs, enabling precise control of field devices such as valves, actuators, pumps, or variable frequency drives. The module integrates seamlessly with ABB FPX series PLCs, controllers, and I/O systems, supporting multi-channel analog output with high industrial reliability.

2. Main Technical Parameters (Typical)

Electrical Data

• Model: FPX-66-9177-B

• Output type: Analog current (4–20 mA) or analog voltage (0–10 V)

• Number of channels: Multi-channel (typically 4 channels)

• Resolution: 16-bit

• Accuracy: ±0.1% FS

• Update rate: ≤ 10 ms

• Output load: Typical 500 Ω (current output)

• Power supply: 24 V DC

• Communication interface: FPX series PLC bus compatible

• Protection features: Overload, short-circuit, overvoltage protection

Mechanical & Installation

• Mounting: DIN rail or modular control cabinet slot

• Dimensions: Standard FPX module size

• Weight: approx. 0.3–0.5 kg

Environmental & Operating Conditions

• Operating temperature: 0°C to +60°C

• Storage temperature: ‑20°C to +70°C

• Relative humidity: 5%–95% (non-condensing)

• EMI/RFI industrial protection design

• Protection level: IP20 (for control cabinet internal use)

Standards & Certifications

• IEC/EN 61131-2

• CE, UL, RoHS certified

3. Advantages and Features

• High-precision output: 16-bit resolution for precise control of actuators and process devices

• Multi-channel support: Simultaneously control multiple analog devices

• Industrial reliability: EMI-resistant, overload, short-circuit, and overvoltage protection

• Modular design: Standard FPX size for easy installation, maintenance, and expansion

• Strong compatibility: Seamless integration with ABB FPX series PLCs and controllers

• Fast response: Update rate ≤ 10 ms, suitable for fast control applications

4. Typical Applications

• Industrial process control (chemical, pharmaceutical, food, metallurgy, etc.)

• Automated production line equipment control

• Precise control of valves, pumps, fans, and actuators

• PLC interface output to field devices

• Analog control output for VFDs, drives, or other industrial devices

5. Application Notes

• Ensure output type (voltage or current) matches the controlled device

• Power supply should be stable 24 V DC

• Install in a well-ventilated, dry control cabinet

• Avoid exceeding module load specifications to prevent abnormal output

• Regularly check terminals and output signals

• Avoid prolonged operation in high humidity, corrosive, or high-EMI environments

The structure and details of the product：

Please make an inquiry for more models
