ABB ACS501-025-3 Control Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

 1. Product Overview

The ABB ACS501-025-3 Control Module is a core control unit in the ACS501 series variable frequency drives (VFDs), used for controlling AC motor speed, torque, and position. The module integrates a high-speed digital processor, power controller, and protection features, providing precise closed-loop control and high-performance motor regulation. The ACS501-025-3 supports multiple communication interfaces and integrates seamlessly with ABB drives and industrial automation systems, widely used in factory automation and process control.

2. Main Technical Parameters (Typical)

Electrical Data

• Model: ACS501-025-3

• Rated current: 25 A

• Rated power: 11–15 kW (depending on motor type)

• Input voltage: 3×380–480 V AC, 50/60 Hz

• Control modes: V/f control, vector control (sensorless or with sensor)

• Output frequency: 0–400 Hz (typical)

• Communication interfaces: Modbus, Profibus, DeviceNet, or ABB industrial bus

• Protection features: Overload, overvoltage, undervoltage, short-circuit, overtemperature, phase-loss protection

• Control response time: <1 ms

Mechanical & Installation

• Mounting: Panel or DIN rail (depending on drive type)

• Dimensions: Compact modular design

• Weight: approx. 3–5 kg

• Cooling: Air-cooled or forced-air cooled

Environmental & Operating Conditions

• Operating temperature: ‑10°C to +50°C

• Storage temperature: ‑20°C to +70°C

• Relative humidity: 5%–95% (non-condensing)

• EMI/RFI industrial protection

• Protection level: IP20–IP54 (depending on installation)

Standards & Certifications

• IEC/EN 61800-5-1/2

• CE, UL, RoHS certified

3. Advantages and Features

• High-performance control: Supports V/f and vector control for precise, high-speed motor operation

• Multiple protection features: Ensures safety and reliability of motors and systems

• Modular design: Easy installation, maintenance, and system expansion

• Strong compatibility: Seamless integration with ACS501 drives and ABB automation systems

• Fast response: <1 ms, suitable for dynamic industrial applications

• Industrial reliability: Vibration-resistant, dust-proof, and EMI-resistant

4. Typical Applications

• Factory automation equipment

• Conveyor belts, mixers, and pump control systems

• HVAC and fan control

• CNC machinery and precision equipment

• Industrial robots and automated production lines

• Process control systems

5. Application Notes

• Ensure module rated current matches motor specifications

• Input voltage must be within rated range

• Install in well-ventilated areas to avoid overheating

• Avoid long-term overload operation

• Regularly inspect terminals and communication interfaces

• Ensure communication protocol is compatible with the system controller

The structure and details of the product：
