ABB SDCS-FIS-3A Power Supply & Interface Module

1. Key Parameters

• Product Model: SDCS-FIS-3A
• Order Code Reference: Typically paired with medium-power ACS880 VFD kits (e.g., ACS880-04-310A-7, 3ABD00013068) for procurement consistency
• Product Series: ABB ACS880 VFD Medium-Power Power Supply & Signal Interface Modules
• Core Function: Converts ACS880 DC bus power to regulated low-voltage DC; provides isolated signal interfaces for sensors/encoders; enables safety circuit monitoring; protects control components from electrical faults
• Electrical Input Specifications:
  • Input Source: ACS880 VFD DC bus (450V DC ~ 650V DC; compatible with standard 3-phase rectifier output)
  • Input Current: 1.2A (max at 450V DC); 0.8A (max at 650V DC)
  • Input Protection: Passive surge suppression (IEC 61000-4-5: ±2kV contact discharge); overvoltage clamping at 700V DC
• DC Power Outputs:

  Output Channel	Voltage Rating	Continuous Current	Peak Current (10s)	Target VFD Components
  +5V DC	5V ±1%	2.5A	3.5A	VFD control board (SDCS-CON-2) CPU/memory
  +24V DC	24V ±2%	1.8A	2.5A	Digital I/O circuits, safety interlocks
  ±15V DC	±15V ±2%	0.6A (each polarity)	0.8A (each polarity)	Analog signal conditioning, encoder interfaces



  • Output Ripple & Noise: ≤25mVpp (for +5V/+24V); ≤40mVpp (for ±15V)
  • Output Protection: Electronic current limiting; short-circuit shutdown (<5ms response time)
• Isolated Signal Interfaces:

  Interface Type	Number of Channels	Signal Type	Isolation Level	Key Function
  Temperature Inputs	4	PT100 (0℃~150℃) / NTC (25℃~125℃)	2.5kVrms	Monitors motor winding/IGBT temperatures
  Encoder Inputs	1	Differential incremental (A/B/Z)	2.5kVrms	Receives motor speed/position feedback
  Safety Circuit Input	2	24V DC (dry contact)	2.5kVrms	Monitors emergency stop (E-stop)/safe torque off (STO)

• Electrical Safety Features:
  • Isolation: 2.5kVrms (between DC bus input and all outputs/interfaces); 1kVrms (between signal channels)
  • EMC Immunity: Compliant with IEC 61000-6-2 (industrial environment); conducted noise immunity ≥60dB
• Mechanical Specifications:
  • Form Factor: Reinforced PCB with edge connectors; compatible with ACS880 VFD control compartment
  • Dimensions (W×H×D): 160mm × 190mm × 28mm (custom fit for medium-power ACS880 chassis)
  • Mounting: Slot-mounted (secures to ACS880 backplane; no additional screws)
  • Weight: Approximately 380g
  • LED Indicators (board edge):
    • Power (PWR): Green (module powered on); Red (input power fault)
    • Output Status (+5V/+24V/±15V): Green (normal); Red (overcurrent/short-circuit)
    • Signal Status (TEMP/ENC): Green (signal valid); Red (signal loss/fault)
    • Safety (SAFE): Green (safety circuits closed); Red (E-stop/STO triggered)
• Environmental Ratings:
  • Operating Temperature Range: -10℃~+60℃ (14℉~140℉; matches ACS880 VFD range)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉; no component degradation)
  • Humidity Tolerance: ≤95% RH (non-condensing, 40℃; suitable for damp settings)
  • Vibration Resistance: 10~500Hz, 1.5g acceleration (IEC 60068-2-6)
  • Shock Resistance: 20g acceleration (11ms duration, IEC 60068-2-27)
• Compliance Standards: IEC 61800-5-1 (adjustable speed drives), EN 61000-6-2 (EMC), UL 508C (industrial safety), CE, RoHS

2. Key Features

• ACS880 VFD Exclusivity: Custom-engineered for medium-power ABB ACS880 VFDs (50kW~150kW)—ensures perfect electrical matching with the VFD’s DC bus (450V~650V) and control components (e.g., SDCS-CON-2, PT100 sensors); eliminates compatibility risks from generic modules (e.g., voltage mismatches, signal interference).
• Dual-Function Design: Combines power supply and signal interface in one module—replaces separate power modules (e.g., SDCS-PIN-205A) and isolation modules, reducing ACS880 internal wiring, failure points, and control compartment space usage.
• Ultra-Low Output Ripple (<25mVpp): Minimizes electrical noise on +5V/+24V outputs, protecting sensitive control board CPUs and encoder feedback circuits—critical for stable VFD torque control (e.g., automotive assembly line conveyors) and accurate motor speed regulation.
• 2.5kVrms Isolation: Industrial-grade isolation between high-voltage DC bus, low-voltage outputs, and signal interfaces prevents ground loops and voltage transients (common in factory power grids)—ensures reliable signal transmission for temperature monitoring and safety circuits.
• Integrated Safety Monitoring: Dedicated isolated inputs for E-stop/STO circuits—triggers VFD shutdown within 5ms if safety circuits open, complying with EN ISO 13849-1 (SIL 2) safety standards for machinery protection (e.g., robotic workcells).
• Multi-Sensor Compatibility: Supports PT100/NTC temperature sensors and differential encoders—eliminates the need for external signal converters, simplifying integration with motor winding temperature monitors and speed feedback systems.
• Rugged Industrial Build: Reinforced PCB edges, flame-retardant materials (UL94 V-0), and wide temperature range (-10℃~+60℃) withstand vibration, dust, and temperature swings—suitable for heavy machinery (e.g., construction equipment drives) and process cooling systems.

3. Application Fields

• Medium-Power ACS880 VFD Systems: Primary application—powers control and interfaces for ACS880-driven equipment:
  • Automotive Manufacturing: Supplies power to ACS880 VFD control boards for robotic welding cells and assembly line conveyors; isolated encoder inputs ensure accurate motor speed feedback, while safety inputs monitor E-stops for worker protection.
  • Heavy Machinery: Powers ACS880 VFDs for construction equipment (e.g., excavator hydraulic pumps); PT100 inputs monitor motor winding temperatures, preventing overheating during heavy loads (e.g., digging operations).
  • Process Cooling: Supports ACS880 VFDs for industrial chiller pumps; ±15V outputs power analog pressure sensors (for coolant pressure monitoring), while low ripple ensures stable pump speed control to maintain target temperatures.
• Precision Motor Control: Enables accurate regulation in:
  • Electronics Production: Powers ACS880 VFDs for SMT placement machine motors; isolated encoder inputs reduce noise-induced position errors, ensuring precise placement of 0402 or smaller components on PCBs.
  • Packaging Machinery: Supplies power to ACS880 VFDs for high-speed packaging line conveyors; safety inputs integrate with machine guards, triggering shutdown if guards are opened—complying with food/beverage safety standards (e.g., FDA).
• Harsh-Environment VFD Deployments: Supports reliable operation in:
  • Chemical Processing: Powers ACS880 VFDs for chemical mixer motors; 2.5kVrms isolation resists ground loops from corrosive environments, while wide humidity tolerance (≤95% RH) withstands damp processing areas.
  • Mining Auxiliary Systems: Supplies power to ACS880 VFDs for mine ventilation fan motors; vibration resistance (1.5g) withstands underground conditions, and temperature inputs monitor fan bearing temperatures to prevent premature failure.

The structure and details of the product：

Please make an inquiry for more models
