ABB PNQ22-FBP.0 (1SAJ261000R0100) PROFINET IO Gateway Module

Critical Correction

1. Model & Part Number Definition

• Full type: PNQ22-FBP.0
• Manufacturing part code: 1SAJ261000R0100
• Product positioning: FBP bus ↔ PROFINET IO Ethernet coupler/gateway
• Core matching device: ABB UMC100.3 universal motor controller (low-voltage motor protection & control unit)

2. Core Technical Specifications

Power & Mechanical

• Supply voltage: 24 V DC
• Mounting: Standard 35mm DIN rail
• Dimensions: 45(W) × 90(H) × 96(D) mm
• Protection rating: IP20 (indoor cabinet only)
• Operating temperature: 0℃ ~ +60℃
• Certifications: PROFINET certified, CE, RoHS compliant

Interface Layout

1. FBP Device Ports (X1~X4)

   4 dedicated FBP bus terminals, support connection of up to 4 units UMC100.3 / UMC100-FBP.0 motor controllers via dedicated flat FBP cables
2. Dual Ethernet RJ45 (E1/E2) Integrated 2-port Switch
   • 10/100Mbps PROFINET IO communication
   • Support MRP ring redundancy (IEC 62439-2) for single cable fault backup
3. USB Service Port

   Local parameter upload/download, firmware upgrade, device diagnosis
4. X6 Power Terminal: 24VDC power input
5. Full LED status indicators: FBP channel status, Ethernet link, fault, running state

Supported Communication Protocols

• Main industrial protocol: PROFINET IO (real-time cyclic data exchange)
• Support SOE time-stamped event logging when matched with ABB AC800xA DCS
• GSDML file provided for integration with Siemens, Rockwell PLC PROFINET masters
• No AS-i / Modbus / EtherNet/IP native support

3. Key Functions

1. Multi-motor controller centralized PROFINET access

   One gateway drives maximum 4 UMC100.3 motor managers, greatly reducing cabinet Ethernet port quantity and wiring cost for multi-motor control panels.
2. FBP bus signal conversion gateway

   Converts proprietary ABB FBP internal bus signals of motor controllers into standard PROFINET industrial Ethernet data, realizing cross-platform PLC data interaction.
3. Complete motor data bidirectional transmission

• Downlink: PLC send motor start/stop, set protection parameters, reset trip faults
• Uplink: Upload motor running current, temperature, overload/alarm codes, maintenance counters, fault logs

4. Redundant ring network support

   Built-in MRP client, form redundant PROFINET ring network to avoid production halt caused by single cable breakage, suitable for process industry high-reliability requirements.
5. Drawable cabinet optimized wiring

   Uses short FBP flat cables inside drawer, no need to lay long Ethernet cables between cabinet drawers, simplifies maintenance of withdrawable motor control cabinets.
6. Local offline diagnosis

   USB port supports offline read/write UMC parameters, view real-time operating data without upper PLC system connection.

4. Compatible Supporting Equipment

ABB Low-Voltage Motor Control System

• UMC100.3 universal motor controller (core matching device)
• PST soft starters with FBP interface
• ABB AC800xA DCS, AC500 PLC PROFINET master stations
• ABB IRC5/OmniCore robot cabinet (cooperate with 3HAC085590-001 teach pendant)

Rockwell Automation Peripheral System

• PLC: SLC 500 (1747-L532), MicroLogix 1200 (1762-L40BWA)
• Servo system: 2094-BC02-M02-M Kinetix 6000 servo drive, H-4050-P-H04AN servo motor
• Network switch: 1783-MMX14T2S Stratix managed Ethernet switch
• Motor protection: 140M-I8P-C50S circuit breaker
• HMI: 2711P-RDB15C PanelView display, GE IC755CSW07CDA touch screen

Field Safety & Signal Components

• Safety relay: 440R-N23126
• Rope pull safety switch: 440E-A13501
• Illuminated pushbutton: 800H-QR10A, contact block 800T-XD2P
• Photoelectric sensor: 871L-D20EP40-N4

5. Typical Industrial Application Scenarios

• Water & sewage treatment multi-pump motor control cabinet
• Petrochemical process plant low-voltage motor central control drawers
• Food & beverage production line conveyor, fan, pump motor management
• Thermal power plant auxiliary equipment motor monitoring system
• Mining process auxiliary motor centralized protection & communication cabinet

6. Important Notes

1. Misconception correction: This is FBP-PROFINET gateway, not AS-i bus gateway, cannot connect AS-i field devices.
2. Each X1~X4 FBP port can only connect one UMC100.3; do not cascade multiple FBP devices on single channel.
3. MRP ring topology requires matching PROFINET managed switch to realize redundant backup function.
4. Must use dedicated ABB FBP flat cable between PNQ22-FBP.0 and UMC100.3; ordinary signal cables will cause communication loss.
5. Separate PROFINET Ethernet cables from high-current motor power cables to reduce electromagnetic interference.
6. Before disassembly, cut off 24VDC power supply to avoid FBP bus interface burnout.
