ABB 1SAM150000R1011 (MS325-12.5) Manual Motor Starter

1. Product Basic Information

• Full part number: 1SAM150000R1011
• Model alias: MS325-12.5
• Series: ABB MS325 DIN rail manual motor starter (integrated motor protection circuit breaker)
• Rated match power: 5.5kW @ 400V three-phase motor

2. Core Technical Specifications

Electrical Parameters

• Poles: 3P three-phase main circuit
• Adjustable thermal overload current range: 9.0 ~ 12.5A
• Instantaneous short-circuit magnetic trip: 10× setting current
• Rated operational voltage: 230~690V AC 50/60Hz
• Insulation voltage: 690V, impulse withstand voltage 6kV
• Trip class: Class 10 standard motor overload characteristic
• Supports single-phase / three-phase motor load protection

Mechanical & Mounting

• Mounting: Standard 35mm TH35 DIN rail
• Overall size: W54 × H87.5 × D75.5 mm
• Weight: 0.34kg
• Wiring: Screw terminal, wire range 1–4mm² solid/stranded copper wire
• Housing protection: IP20 (indoor cabinet use only)
• Operation mode: Rotary handwheel manual ON/OFF switching, with dedicated TEST test button

Environmental & Protection Features

• Operating ambient temperature: -25℃ ~ +50℃ (temperature compensated bimetallic strip)
• Built-in phase loss / three-phase unbalance protection
• Trip-free safety mechanism (cannot hold closed position under fault state)
• Short-circuit breaking capacity, full fuseless motor branch protection
• Visible mechanical handle position indicator (ON/OFF/TRIP)

3. Key Integrated Functions

1. Manual motor direct switching

   Rotary knob realizes direct on-line start/stop of small and medium motors, integrates isolation disconnect function for maintenance power cut-off.
2. Multi-layer motor comprehensive protection

• Thermal overload delayed trip: Prevent winding burnout from long-term overloading
• Instantaneous magnetic short-circuit trip: Rapid cut-off phase-to-phase short fault
• Phase loss protection: Avoid single-phase operation burning three-phase motors

3. No external fuse required

   Integrated thermal-magnetic trip unit, saves cabinet space and simplifies power distribution wiring compared to fuse + contactor schemes.
4. Test maintenance function

   Front TEST button simulates overload trip to verify protection circuit integrity without loading the motor.
5. Expandable auxiliary signal feedback

   Can be matched with auxiliary contact accessories to output trip fault signal to PLC digital input modules for HMI alarm display.

4. Compatible Matching Automation Equipment

ABB Low Voltage & Fieldbus System

• ABB PNQ22-FBP.0 (1SAJ261000R0100) PROFINET FBP gateway
• ABB UMC100.3 motor management relay
• ABB IRC5 robot cabinet + 3HAC085590-001 teach pendant

Rockwell Automation Peripherals

• PLC: SLC 500 1747-L532 / MicroLogix 1200 1762-L40BWA
• Servo system: 2094-BC02-M02-M Kinetix 6000 drive, H-4050-P-H04AN servo motor
• Network switch: 1783-MMX14T2S Stratix managed Ethernet switch
• Safety components: 440R-N23126 safety relay, 440E-A13501 rope pull switch
• Operator parts: 800H-QR10A pushbutton, 800T-XD2P contact block
• Sensor: 871L-D20EP40-N4 photoelectric switch
• HMI: 2711P-RDB15C PanelView display, GE IC755CSW07CDA touch screen

5. Typical Industrial Application Scenarios

• Water & sewage treatment pump, fan motor local control cabinet
• Food & beverage packaging line small conveyor motor branch protection
• HVAC cooling tower blower, air handler motor starter panel
• Petrochemical auxiliary small pump, agitator motor control circuit
• Machine tool auxiliary feed motor, dust removal fan protection
