ABB 4414129285 E183012 Permanent Magnet DC Servo Motor

Critical Correction

1. Full Nameplate Parameter Specification

• Model No.: 4414129285 / E183012
• Type: Permanent Magnet DC Servomotor
• Continuous Stall Torque: 1.8 N·m
• Peak Stall Torque: 7.2 N·m
• Torque Constant Kt: 0.33 N·m/A
• Rated Back EMF: 42 V
• Max Continuous Current: 24 A
• Rated Speed: 1200 RPM
• Insulation Class: F
• Protection Grade: IP44
• Manufacturer: ABB Servomotors S.r.l. (Italy)
• Built-in: Tachogenerator feedback interface, optional brake mounting port

2. Mechanical & Structure Features

• Cylindrical heavy-duty metal housing, IP44 dust/water splash resistant
• Solid keyed output shaft, standard timing pulley mounting interface
• Dual integrated side connectors:
  1. Power winding connector
  2. Tachometer feedback signal connector for closed-loop speed control
• Rear mounting flange for direct machine frame installation
• Internal high-performance neodymium permanent magnet rotor, low cogging torque

3. Core Working Functions

1. Closed-loop precision speed & position driving

   Matched with ABB DC servo drives, uses built-in tachogenerator to feed real-time motor speed back to drive, forming high-stability velocity closed loop for constant tension, positioning applications.
2. Wide torque output range

   1.8Nm continuous torque for steady running; peak 7.2Nm overload torque for fast acceleration/deceleration of conveyors, winding rolls, cutting axes.
3. Compact integrated feedback design

   No separate external encoder required; onboard tacho simplifies cabinet wiring, reduces signal interference risk.
4. Harsh workshop environmental adaptability

   IP44 housing resists dust, coolant mist and light splashing, suitable for metal processing, printing, packaging equipment.
5. Expandable brake function

   Reserved internal mounting space to install holding brake for vertical axes, preventing load sliding after power loss.

4. Compatible Matching Automation Equipment

Drive & Motion Control

• ABB DCS500 / DCS800 DC servo drives (main matching drive series)
• ABB IRC5 / OmniCore robot controllers (coordinate with 3HAC085590-001 teach pendant)

Rockwell Peripheral System

• PLC: SLC 500 (1747-L532), MicroLogix 1200 (1762-L40BWA)
• Servo Drive: 2094-BC02-M02-M Kinetix 6000 multi-axis drive
• Feedback Cable: 2090-CFBM7DF-CEAF60 continuous-flex encoder cable

Field Sensors & Safety Components

• Photoelectric sensor: 871L-D20EP40-N4
• Safety relay: 440R-N23126
• Rope pull switch: 440E-A13501
• Pushbutton & contact block: 800H-QR10A, 800T-XD2P

Power & Network

• Motor protection circuit breaker: 140M-I8P-C50S
• Managed industrial switch: 1783-MMX14T2S

HMI Terminals

• ABB FlexPendant 3HAC085590-001
• Rockwell PanelView 2711P-RDB15C, GE IC755CSW07CDA touch screen

5. Typical Industrial Application Scenarios

• Printing & textile constant tension unwinding/winding machines
• Metal slitting, cutting, rewinding precision speed control axes
• Packaging film stretching, roll positioning servo systems
• Conveyor variable-speed precise material transport lines
• Machine tool auxiliary feed axis speed regulation

6. Certifications & Important Notes

1. Certifications: CE, UL, Class F winding insulation compliant
2. This is a DC servo motor, cannot be replaced with AC brushless servo motors (e.g. H-4050-P-H04AN) directly; drive power stage must match DC voltage class.
3. Tachogenerator signal cable must use shielded wiring and separate from high-current power cables to avoid speed fluctuation interference.
4. Disconnect all DC drive power before plugging/unplugging motor connectors to prevent tacho circuit burnout.
5. IP44 only protects the motor body; install additional protective cover if equipment is exposed to heavy water jet washing.
6. If vertical axis holding is required, select matching ABB brake accessory kit for this motor model.
