ABB 3HAC085590-001 (DSQC3120 SxTPU4) Robot FlexPendant Teach Pendant

Product Correction

1. Model Definition

• Part No.: 3HAC085590-001
• Hardware model: DSQC3120 SxTPU4
• Product type: 7-inch industrial robot teach pendant (FlexPendant)

2. Core Hardware Specifications

Display & Operation Interface

• Screen: 7" TFT color touch LCD
• Resolution: 800 × 480 WVGA
• Operation: Capacitive touch screen + physical hard key array
• Hard buttons: 16 function keys, 4 directional keys, 3-stage deadman enable switch, integrated emergency stop button
• Safety design: Dual-channel enable switch, E-stop hard-wired safety circuit

Electrical Parameters

• Rated input voltage: 24VDC
• Max power consumption: 20W
• Communication interface: Special robot bus cable connection to IRC5 / OmniCore controller
• Built-in USB 2.0 port: Program backup, firmware upgrade, log export

Mechanical & Environmental

• Front panel protection: IP65 dustproof, waterproof, oil-resistant
• Operating temperature: 0℃ ~ +60℃
• Storage temperature: -20℃ ~ +70℃
• Humidity: 5%–95% RH non-condensing
• Ergonomic handheld shell, anti-slip rubber grip, wearable lanyard interface

3. Main Functions

1. Robot manual jog teaching

   Real-time jog control of 6-axis robot joints or Cartesian linear movement, create and modify RAPID robot motion programs, adjust workpiece coordinate systems.
2. Real-time system monitoring

   Display robot axis load, speed, servo temperature, I/O signal status, fault alarm codes, motion path preview on touch screen.
3. Safety interlock operation

   3-position deadman switch (release = stop, half-press = manual jog, full press = safety trigger stop) + integrated emergency stop button, complies with ISO 10218 robot safety standards.
4. Program management & data storage

   Upload/download robot RAPID programs, backup system configuration, export production operation logs via local USB port.
5. External peripheral debugging

   Monitor and trigger robot grippers, photoelectric sensors, conveyor I/O signals, coordinate with peripheral PLCs for joint debugging.
6. Multi-language system support

   Built-in Chinese, English, German and other multi-language operation interfaces, adaptable to global production lines.

4. Compatible Robot Controllers

• IRC5 / IRC5 Compact / IRC5 Single cabinet robot controllers
• OmniCore E10 / C30 / C90XT new generation robot control cabinets
• Matching robot series: IRB 1200, IRB 2600, IRB 6700, IRB 1410, collaborative robots etc.

5. Matching Peripheral Automation Equipment

1. Robot peripheral sensors & switches

   871L-D20EP40-N4 photoelectric sensor, 440E-A13501 rope pull safety switch, 800H-QR10A illuminated pushbutton, 800T-XD2P contact block
2. Safety control components

   440R-N23126 safety relay for E-stop and safety door interlock circuits
3. PLC & Motion Drive

   Rockwell SLC 500 / MicroLogix 1200 / ControlLogix + 2094-BC02-M02-M Kinetix servo drive
4. Power & Network

   140M-I8P-C50S motor protection circuit breaker, 1783-MMX14T2S managed industrial Ethernet switch
5. HMI

   2711P-RDB15C PanelView display module, GE IC755CSW07CDA touch panel

6. Typical Industrial Applications

• Automotive welding, handling, painting robot stations
• 3C electronics assembly, screw locking, dispensing robot cells
• Food & packaging robotic palletizing, depalletizing lines
• Metal cutting, grinding, machine tool loading/unloading robots
• Logistics warehouse automated sorting robot systems

7. Certifications & Important Notes

1. Certifications: CE, UL, ISO 10218 industrial robot safety certified
2. IP65 front panel only; avoid long-term immersion in water or chemical liquid splashing.
3. The 3-stage deadman switch is mandatory safety component; equipment cannot run in manual mode if damaged.
4. Must use dedicated ABB robot teach pendant cable to connect controller; ordinary Ethernet cables cannot be used.
5. Disconnect robot controller main power before plugging/unplugging the pendant cable to prevent communication board burnout.
6. Integrated E-stop signal is hard-wired to the robot safety circuit, independent of software control.
7. This is a complete handheld teaching terminal, different from internal controller main boards, servo drive boards and I/O boards inside the IRC5 cabinet.
