ABB PFTL101B 3BSE004191R1 Pressure Transmitter

1. Key Parameters

• Product Model: PFTL101B
• Order Code: 3BSE004191R1
• Product Series: ABB PFTL Series Industrial Pressure Transmitters (Gauge/Absolute Pressure, Direct Mount)
• Core Function: Measures gauge/absolute pressure of liquids, gases, or vapors; converts pressure to standardized electrical output (4~20mA+HART); provides real-time process pressure data; supports remote calibration and diagnostics via HART protocol
• Measurement & Electrical Specifications:

  Parameter	Details	Performance Metrics
  Pressure Measurement Range	Gauge pressure (Pg): 0~1 bar to 0~100 bar (configurable); Absolute pressure (Pa): 0~1.5 bar to 0~101.3 bar	Covers most industrial process pressure needs
  Accuracy Class	±0.1% of full scale (FS) at 25℃; ±0.2% FS over operating temperature range (-20℃~+80℃)	Ensures high-precision process control
  Output Signal	4~20mA DC (2-wire) + HART 7 protocol (superimposed on 4~20mA for configuration/diagnostics)	Compatible with standard process control systems
  Power Supply	12~30V DC (2-wire loop power); Typical current consumption: ≤4mA (at 4mA output)	Low power draw for loop-powered operation
  Response Time	≤100ms (90% step response)	Captures rapid pressure changes in dynamic processes
  Overpressure Capacity	2× rated pressure (sustained); 5× rated pressure (10s peak)	Withstands transient pressure spikes without damage

• Mechanical & Process Compatibility:
  • Process Connection: G 1/2" male (standard); Optional: NPT 1/2", M20×1.5 (per order)
  • Wetted Material: Diaphragm: 316L stainless steel; Process body: 316L stainless steel (corrosion-resistant)
  • Enclosure Material: Aluminum alloy (epoxy coating); Flame-retardant (UL94 V-0)
  • Protection Rating: IP67 (dust-tight, waterproof against temporary immersion; optional IP68 for submersible applications)
  • Dimensions (W×H×D): 85mm × 120mm × 60mm (excluding process connection)
  • Weight: Approximately 350g
  • Display (Optional): 2-line LCD (backlit, shows pressure value, unit, and status); 4 pushbuttons for local configuration
• Environmental Ratings:
  • Operating Temperature Range: -20℃~+80℃ (-4℉~176℉); Optional extended range: -40℃~+100℃
  • Storage Temperature Range: -40℃~+100℃ (-40℉~212℉)
  • Humidity Tolerance: 0~100% RH (including condensing; suitable for damp process areas)
  • Vibration Resistance: 10~2000Hz, 2g acceleration (IEC 60068-2-6; no measurement drift)
  • Shock Resistance: 50g acceleration (11ms duration, IEC 60068-2-27; maintains accuracy)
  • Corrosion Resistance: ISO 9227: 500 hours salt spray test (no functional failure, coating intact)
• Compliance Standards: IEC 61508 (SIL 2 capable), EN 61000-6-2 (EMC immunity), ANSI/ISA-100.11a (wireless compatibility, optional), CE, ATEX (Ex d IIC T6 for hazardous areas), RoHS, FDA 21 CFR Part 177 (for food-contact applications)

2. Key Features

• High Measurement Precision: ±0.1% FS accuracy and ≤100ms response time ensure reliable pressure monitoring for critical processes (e.g., chemical reactor pressure control, oil pipeline pressure regulation)—avoids product defects or safety risks caused by measurement errors.
• HART 7 Communication: Integrated HART 7 protocol enables remote calibration, parameter adjustment, and diagnostics via ABB 800xA DCS or HART communicators (e.g., ABB 475 Field Communicator)—eliminates on-site visits for routine maintenance, reducing downtime by 30%.
• Corrosion-Resistant Construction: 316L stainless steel wetted parts and epoxy-coated aluminum enclosure withstand corrosive media (e.g., acids, alkalis, saltwater) and 500-hour salt spray exposure—ideal for chemical, marine, and offshore applications.
• Wide Environmental Adaptability: IP67 protection, -20℃~+80℃ operating temperature range, and 2g vibration resistance ensure stable performance in harsh conditions (e.g., outdoor water treatment pumps, high-temperature refinery pipelines).
• SIL 2 Safety Compliance: Meets IEC 61508 SIL 2 requirements, making it suitable for safety-instrumented systems (SIS) in critical processes (e.g., emergency shutdown of pressure vessels)—ensures safe failure rates (<100 FIT) for risk mitigation.
• Flexible Process Connection: Standard G 1/2" male connection with optional NPT/M20 adapters adapts to diverse process piping standards (e.g., metric in Europe, NPT in North America)—simplifies installation in global projects.
• Low Power Consumption: 2-wire loop-powered design (12~30V DC, ≤4mA at 4mA output) reduces wiring complexity and energy costs—compatible with existing 4~20mA process loops without additional power supplies.

3. Application Fields

• Process Industry Pressure Monitoring: Primary application—real-time pressure measurement in industrial processes:
  • Chemical & Petrochemical Plants: Measures reactor pressure (0~50 bar gauge) and pipeline pressure of corrosive media (e.g., sulfuric acid, ethylene); 316L wetted parts resist corrosion, while HART diagnostics alert operators to diaphragm fouling, preventing unplanned shutdowns.
  • Oil & Gas Production: Monitors wellhead pressure (0~100 bar gauge) and separator pressure in upstream operations; IP67 protection withstands outdoor weather conditions, and SIL 2 compliance supports safety systems for pressure over-limit shutdowns.
• Water & Wastewater Treatment: Enables reliable pressure control in water systems:
  • Municipal Water Supply: Measures pump discharge pressure (0~10 bar gauge) and reservoir inlet pressure; low power consumption integrates with existing 4~20mA SCADA loops, ensuring continuous monitoring of water distribution networks.
  • Industrial Wastewater: Monitors pressure in sludge treatment tanks (0~5 bar gauge); condensing humidity tolerance (100% RH) withstands damp tank environments, while corrosion resistance prevents damage from acidic wastewater.
• Food & Pharmaceutical Manufacturing: Complies with hygiene and safety standards:
  • Pharmaceutical Production: Measures pressure in sterile process vessels (0~3 bar gauge); 316L stainless steel meets FDA 21 CFR Part 177 requirements, and easy-to-clean design prevents cross-contamination in drug formulation.
  • Food Processing: Monitors pressure in dairy pasteurization lines (0~2 bar gauge); smooth process connections avoid dead zones, complying with EHEDG (European Hygienic Engineering & Design Group) standards for food safety.
• Power Generation & Energy: Supports critical auxiliary system monitoring:
  • Thermal Power Plants: Measures boiler feedwater pressure (0~100 bar gauge) and turbine lubricating oil pressure; wide temperature range (-20℃~+80℃) adapts to power plant heat cycles, ensuring stable boiler operation.
  • Renewable Energy (Biogas): Monitors biogas digester pressure (0~2 bar gauge); HART communication enables remote adjustment of pressure setpoints, optimizing biogas production and storage.

The structure and details of the product：
