ABB FENA-11 Ethernet Adapter Module

Product Description

ABB FENA-11 is an Ethernet Adapter Module / Fieldbus Adapter designed for ABB variable frequency drives (VFDs). It provides Ethernet-based communication capability for ABB drives, enabling integration with PLC systems, industrial networks, and automation platforms.

The module supports multiple industrial Ethernet protocols, including EtherNet/IP, Modbus TCP, and PROFINET IO, allowing ABB drives to communicate with various control systems.

Specifications

• Brand: ABB
• Model: FENA-11
• Product Type: Ethernet Adapter Module / Fieldbus Communication Module
• Communication Interface: Industrial Ethernet
• Ethernet Port: 1 × RJ45
• Communication Speed: 10/100 Mbps
• Supported Protocols:
  • EtherNet/IP
  • Modbus TCP
  • PROFINET IO
• Mounting: Internal option module for ABB drives
• Power Supply: Supplied from drive control unit
• Operating Temperature: Approx. -20…+70 °C
• Cable Type: CAT5 Ethernet cable

Compatible ABB Drives

FENA-11 is commonly used with ABB drive families including:

• ACS355
• ACS380
• ACS480
• ACS580
• ACS850
• ACS880
• ACQ580
• ACH580
• ACSM1

Functions

• Adds Ethernet communication capability to ABB drives
• Enables PLC control and monitoring of drive parameters
• Transfers speed, torque, current, status, and diagnostic information
• Supports remote drive configuration
• Provides communication between inverter and industrial networks
• Allows integration into factory automation systems

Advantages & Features

• Supports multiple Ethernet communication standards
• Simplifies ABB drive integration into automation networks
• Reduces traditional hardwired control wiring
• Provides real-time drive monitoring and diagnostics
• Compact plug-in design for ABB drives
• Suitable for industrial Ethernet applications

Applications

• Variable frequency drive control systems
• Factory automation networks
• PLC and SCADA communication
• Motor control systems
• Conveyor systems
• Pump and fan applications
• Process automation equipment

Notes

• FENA-11 is a communication adapter module, not a standalone Ethernet switch
• Requires a compatible ABB drive for operation
• Confirm drive model compatibility before installation
• Configure communication parameters according to PLC protocol
• Check firmware compatibility when replacing existing modules
