ABB CP430B 3ABD10093882 Operator Panel

Product Description

ABB CP430B (3ABD10093882) is a CP400 Series Operator Panel / HMI (Human Machine Interface) designed for industrial automation applications. It provides an operator interface for machine control, process monitoring, alarm display, and communication with PLC and automation systems.

The CP430B features a 5.7-inch monochrome touch display, integrated function keys, and multiple communication interfaces, making it suitable for compact machine control and industrial visualization applications.

Specifications

• Brand: ABB
• Model: CP430B
• Order Code: 3ABD10093882 / 1SBP260183R1001
• Product Type: Operator Panel / HMI Terminal
• Series: CP400
• Display Size: 5.7 inch
• Display Type: STN Monochrome LCD (16 shades of blue)
• Resolution: 320 × 240 pixels
• Touch Screen: Analog resistive touch
• Function Keys: 5 user keys + 1 Menu key
• Power Supply: 24V DC ±15%
• Power Consumption: < 20 W (approx. <840 mA)
• Communication Interfaces: 2 × serial communication ports
• Flash Memory: 4 MB
• RAM: 512 KB
• Real-Time Clock: Supported (with rechargeable lithium battery)
• Protection Rating: IP65 front panel
• Mounting: Panel Mount
• Dimensions: Approx. 195 × 145 × 60 mm
• Weight: Approx. 0.81 kg

Functions

• Provides operator-machine interaction
• Displays machine status and process information
• Allows operator input through touchscreen and function keys
• Displays alarms and diagnostic messages
• Stores and executes HMI applications
• Communicates with PLC controllers and automation devices
• Supports industrial equipment monitoring and control

Advantages & Features

• Compact industrial HMI design
• 5.7-inch touch display for easy operation
• Integrated function keys for quick commands
• Reliable 24V DC industrial power supply
• Supports multiple communication protocols
• Suitable for legacy automation systems
• IP65 front protection for industrial environments
• Long-life industrial display design

Applications

• Factory automation systems
• Machine control panels
• Packaging equipment
• Production lines
• Process monitoring systems
• PLC operator stations
• Industrial equipment control cabinets

Notes

• CP430B is an HMI operator panel, not a PLC controller
• Requires compatible ABB configuration software for programming
• Confirm PLC communication protocol before replacement
• Check 24V DC power supply polarity before installation
• Contains a rechargeable lithium battery for RTC function; shipping may require battery consideration depending on carrier requirements
