ABB ED1822A Interface Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB ED1822A Interface Board is a signal conversion and interface device used in ABB automation systems. It connects and coordinates digital or analog signals between different modules. The board provides reliable data transmission and signal isolation to ensure stable operation of the control system. ED1822A is widely used in ABB DCS, PLC, and industrial automation systems for control signal processing, I/O expansion, and system communication.

2. Technical Specifications

• Model: ED1822A

• Product Type: Interface Board

• Signal Type: Digital I/O / Analog I/O (system dependent)

• Number of Interfaces: 16 channels (example, configurable)

• Isolation Voltage: ≥ 500 V DC

• Operating Voltage: 24 V DC

• Power Consumption: ≤ 3 W

• Mounting: Insert into control system backplane

• Operating Temperature: 0 ℃ to +60 ℃

• Degree of Protection: IP20

• Standards: IEC 61131 / CE

3. Advantages and Features

1. Reliable Signal Transmission
   Supports multiple input and output channels to ensure stable system signals.

2. Electrical Isolation Design
   Provides isolation voltage protection to prevent interference between modules.

3. Flexible Expansion
   Can expand I/O channels to meet system extension requirements.

4. Industrial Adaptability
   Stable operation under high temperature, vibration, and harsh industrial environments.

5. Easy Installation
   Plug-in design allows quick installation and replacement in control cabinets.

4. Applications

• ABB DCS and PLC system signal expansion

• Industrial automation process control

• Production line monitoring and data acquisition

• Power and energy management systems

• Machinery control and monitoring

5. Installation and Usage Notes

1. Ensure the interface board model is compatible with the control system before installation.

2. Insert and wire with power disconnected to ensure safety.

3. Avoid incorrect wiring; ensure proper connection of input/output terminals.

4. Regularly inspect the interface board and connections to ensure long-term reliable operation.

5. Avoid direct use in high humidity, dusty, or corrosive environments; provide protective covers if necessary.
