ABB 1SAM150000R1009 Manual Motor Starter

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 1SAM150000R1009 Manual Motor Starter is a protective and control device for low-voltage motors. It combines an overload relay with a manual switch to control motor start/stop operations and provide overload protection. This starter effectively protects motors from overcurrent, short-circuit, and phase-failure faults and is suitable for direct-on-line or star-delta starting applications. It is ideal for small to medium AC motors in industrial, commercial, and building environments.

2. Technical Specifications

• Model: 1SAM150000R1009

• Product Type: Manual Motor Starter

• Rated Current: 0.1–0.16 A (adjustable overload range)

• Rated Voltage: AC 690 V

• Poles: 3

• Contact Type: Normally Open + Overload Relay

• Mechanical Life: ≥ 10,000 operations

• Electrical Life: ≥ 4,000 operations (rated load)

• Operation: Manual knob operation

• Mounting: DIN rail or panel mount

• Degree of Protection: IP20

• Operating Temperature: –25 ℃ to +60 ℃

• Standards: IEC 60947-4-1 / CE

3. Advantages and Features

1. Comprehensive Motor Protection
   Integrated overload, short-circuit, and phase-failure protection ensures safe motor operation.

2. Easy Operation
   Manual knob with clear ON/OFF indication for convenient field use.

3. Adjustable Settings
   Overload protection range can be adjusted to match motor rated current.

4. Industrial Durability
   High mechanical and electrical life suitable for frequent industrial operation.

5. Convenient Installation
   DIN rail or panel mounting allows easy integration into control cabinets or distribution systems.

4. Applications

• Industrial low-voltage AC motor control

• Fans, pumps, compressors, and other motor-driven equipment

• Factory automation and production line motor protection

• Building and commercial motor control systems

• Small machinery and power distribution systems

5. Installation and Usage Notes

1. Verify the rated current and voltage match the motor before installation.

2. Perform wiring and installation with power disconnected for safety.

3. Ensure smooth knob operation and proper overload adjustment per motor rating.

4. Regularly inspect terminals and overload relay status for long-term reliable operation.

5. Avoid direct use in high humidity, dusty, or corrosive environments; provide protective measures if necessary.
