ABB 3BHE024747R0101 AC800F Control Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 3BHE024747R0101 AC800F Control Board is a core processing unit of the ABB AC800F control system, used for process automation and data processing. The control board integrates a high-speed processor, I/O interfaces, and communication modules to execute control strategies in real time, providing precise process control and system monitoring. It is widely used in power, petrochemical, metallurgy, paper, pharmaceutical, and other industrial automation applications, serving as a key component of the AC800F system.

2. Technical Specifications

• Model: 3BHE024747R0101

• Product Type: AC800F Control Board

• Processor Type: High-speed embedded CPU

• Input/Output Interfaces: Digital I/O, Analog I/O (expandable modules)

• Communication Interfaces: Ethernet, PROFIBUS, Modbus, etc. (system dependent)

• Operating Voltage: 24 V DC

• Power Consumption: ≤ 15 W

• Operating Temperature: 0 ℃ to +55 ℃

• Storage Temperature: –40 ℃ to +70 ℃

• Degree of Protection: IP20

• Mounting: Insert into AC800F control rack

• Standards: IEC 61131 / CE / UL

3. Advantages and Features

1. High-Performance Processing
   High-speed embedded CPU can process complex control logic and data calculations in real time.

2. Multiple Interface Support
   Offers rich digital/analog I/O and industrial communication interfaces for easy system integration.

3. Modular Design
   Can be combined with other AC800F modules for flexible system expansion and upgrades.

4. Stable and Reliable
   Industrial-grade design ensures long-term stable operation in high temperature, vibration, and EMI environments.

5. Strong System Compatibility
   Fully compatible with ABB AC800F control systems, supporting multiple control strategies and application software.

4. Applications

• Power and energy management systems

• Petrochemical, chemical, and metallurgical industrial automation

• Paper, pharmaceutical, and food processing control

• Factory production line automation and data acquisition

• HVAC systems and building automation control

5. Installation and Usage Notes

1. Ensure the control board model is compatible with the AC800F system rack before installation.

2. Perform wiring and installation with power disconnected to ensure safety.

3. Avoid electrostatic damage; use anti-static wrist straps during installation.

4. Regularly check module operation and communication connections to maintain system stability.

5. Avoid direct use in high humidity, dusty, or corrosive environments; provide protective enclosures if necessary.
