ABB DSQC358G 3HAB8101-16/10A servo rectifier unit

ABB DSQC358G 3HAB8101-16/10A Servo Rectifier Unit

Product Overview

The ABB DSQC358G 3HAB8101-16/10A Servo Rectifier Unit is a high-performance industrial rectifier module, specifically designed for ABB's servo drive systems. The primary function of this module is to convert three-phase AC power into stable DC power, providing a reliable power supply to servo motors and servo drive systems. With its efficient power conversion and strong control capabilities, the DSQC358G ensures smooth and precise operation of servo systems. Its design supports high-power, high-precision motion control requirements in various automation systems, making it widely used in robotic systems, CNC machines, and automated production lines.

Technical Specifications

• Model: DSQC358G 3HAB8101-16/10A

• Type: Servo Rectifier Unit

• Input Voltage: 3x400V~3x480V AC (three-phase)

• Output Voltage: DC output, typically ±325V DC

• Rated Current: 10A

• Output Power: Suitable for medium-power servo systems

• Cooling Method: Forced air cooling

• Operating Temperature Range: -10°C to 50°C

• Dimensions: 280mm x 200mm x 120mm

• Weight: 3.5 kg

• Mounting: Suitable for DIN rail installation, adaptable to various industrial environments

• Communication Interface: Compatible with ABB servo systems, supports multiple industrial communication protocols (e.g., Ethernet, Profibus)

Advantages & Features

1. Efficient Power Conversion: The DSQC358G module utilizes advanced rectification technology to efficiently convert AC power into stable DC power, ensuring smooth operation of servo systems even under heavy loads.

2. High Current Capacity: With a rated current of 10A, the DSQC358G is designed for medium-power servo systems, meeting the power needs of a wide range of industrial applications.

3. Wide Input Voltage Range: The module supports an input voltage range of 3x400V~3x480V AC, offering high compatibility with various electrical standards in different regions.

4. High Reliability & Durability: Built with high-quality electronic components, the module has strong anti-interference capabilities and long operational life, making it suitable for demanding industrial environments.

5. Compact Design: The compact design of the module allows for installation in space-constrained environments, and it supports DIN rail mounting for easy integration into existing systems.

6. Cooling System: Equipped with a forced air cooling system, the module helps maintain a stable operating temperature, enhancing its longevity and reliability.

7. Multi-Protocol Support: The DSQC358G supports multiple communication protocols, including Ethernet and Profibus, ensuring seamless integration with ABB servo control systems for efficient operation.

Application Fields

• Servo Drive Systems: The DSQC358G is a critical component of high-performance servo drive systems, providing stable power to servo motors, ensuring high-precision and efficient motion control in industrial robots, CNC machines, and other precision machinery.

• Automated Production Lines: In automated production lines, the DSQC358G provides stable power support for machinery, ensuring continuous, high-efficiency operation, especially during precision assembly and machining processes.

• Robotic Systems: In industrial robot systems, the module supplies stable DC power to servo drives, ensuring robots can perform complex tasks with high precision and efficiency.

• Precision Control Applications: In fields requiring high-precision control, such as semiconductor production, electronic manufacturing, and more, the DSQC358G provides stable power to servo systems, ensuring high precision and stability.

Precautions

1. Power Connection: Ensure correct wiring to avoid reverse connections or poor connections, which could lead to module damage or malfunction.

2. Environmental Temperature Requirements: Make sure the operating environment temperature remains between -10°C and 50°C to prevent performance issues in high-temperature environments.

3. Cooling System Maintenance: Regularly inspect the cooling system and ensure that fans are operating properly to prevent overheating and module failure.

4. Communication Line Inspection: Periodically check communication interfaces and lines for loose connections, corrosion, or damage to ensure stable data transmission.

5. Regular Maintenance: Perform regular inspections and maintenance, especially in high-load or high-frequency applications, to ensure stable system operation.
