ABB 3HAB8101-14 DSQC345E servo drive rectifier module

ABB 3HAB8101-14 DSQC345E Servo Drive Rectifier Module

Product Overview

The ABB 3HAB8101-14 DSQC345E Servo Drive Rectifier Module is a core component of ABB’s automation and drive systems, widely used in industrial applications. This module efficiently converts AC power into DC power, providing stable and reliable energy to servo drive systems. As an integral part of ABB's servo drive series, the DSQC345E module is designed to work seamlessly with a variety of ABB servo drive systems, ensuring efficient power conversion and stable operation. Its outstanding power control capabilities and reliability make it ideal for precision motion control, automation production lines, and robotic systems.

Technical Specifications

• Model: 3HAB8101-14 DSQC345E

• Type: Servo Drive Rectifier Module

• Input Voltage Range: 3x400V~3x480V AC (three-phase)

• Output Voltage: DC voltage output, typically ±325V DC

• Output Power: Suitable for medium to high-power servo drive systems

• Rated Current: Maximum 40A (depending on load requirements)

• Communication Interface: Direct connection with servo control systems, supporting Industrial Ethernet, Profibus, and other communication protocols

• Cooling Method: Forced air cooling

• Operating Temperature Range: -10°C to 50°C

• Dimensions: 280mm x 200mm x 120mm

• Weight: 3.5 kg

• Mounting: Suitable for DIN rail or panel mounting

Advantages & Features

1. Efficient Power Conversion: The DSQC345E module utilizes advanced rectification technology to efficiently convert three-phase AC power into DC power, ensuring stable operation of servo drive systems.

2. Wide Input Voltage Compatibility: It supports an input voltage range of 3x400V~3x480V AC, offering high compatibility with various voltage standards across regions.

3. Compact Design & Easy Integration: The module features a compact design, easy to install with DIN rail or panel mounting, making it simple to integrate with other ABB servo drive systems.

4. High Current Handling Capacity: The DSQC345E supports up to 40A of output current, making it suitable for medium to high-power servo systems.

5. High Reliability: Built with high-quality components and strong anti-interference capabilities, the module ensures stable operation in complex industrial environments.

6. Cooling System: Equipped with a forced air cooling system, the module effectively reduces heat buildup during operation, extending its lifespan and reliability.

7. Multi-Protocol Support: The module supports communication via Ethernet, Profibus, and other industrial protocols, ensuring seamless integration with ABB servo control systems.

Application Fields

• Servo Control Systems: The DSQC345E is a crucial part of high-performance servo control systems, used in automation tasks that require precise motion control, such as in robots, CNC machines, and other precision machinery.

• Automation Production Lines: In automation production lines with high-precision motion control, the DSQC345E provides stable power support, ensuring the continuous and efficient operation of equipment.

• Robotic Systems: The DSQC345E module supplies a stable DC power source to servo drives in industrial robot systems, ensuring high efficiency and precision during complex tasks.

• High-Precision Motion Control Applications: In industries requiring high-precision motion control, such as semiconductor production, precision instruments, and packaging machinery, the module offers stable and efficient power support.

Precautions

1. Power Connection: Ensure correct wiring when connecting the power supply to prevent reverse wiring or poor connections that could damage the module.

2. Environmental Temperature Requirements: Install the module in environments with temperatures between -10°C and 50°C to avoid performance issues in high-temperature environments.

3. Cooling System Maintenance: Regularly check the cooling system, ensuring the fans are operating correctly to prevent module failure due to overheating.

4. Regular Maintenance: Inspect electrical connections and module status regularly to ensure there are no loose, corroded, or damaged components, ensuring long-term stable operation.

5. Avoid Electromagnetic Interference: Install the module away from strong electromagnetic interference sources to minimize external electromagnetic effects on module performance.

6. ​The structure and details of the product：
7.
