Product Information: ABB DCPT-01 Drive Cable

Detailed Specifications:

• Model: DCPT-01

• Type: Drive Cable

• Application: Used for connecting drives to motors, ensuring stable power and control signal transmission in drive systems

• Cable Specifications:

  • Cable Type: Shielded multi-core cable with excellent anti-interference properties

  • Conductor Type: Copper conductors (high conductivity)

  • Cable Outer Sheath: PVC or polyethylene material, abrasion-resistant and corrosion-resistant

  • Shielding Type: Shielded construction providing protection against electromagnetic interference (EMI)

  • Cable Size: Available in various sizes from 1.5 mm² to 25 mm², depending on the drive requirements

• Rated Voltage: 600/1000 V

• Rated Current: Varies depending on cable model and length

• Temperature Range:

  • Operating Temperature: -5°C to +70°C

  • Storage Temperature: -40°C to +80°C

• Protection Rating: IP20

• Standards Compliance: IEC, UL, RoHS certified

• Length Options: Customizable lengths available upon request

Product Advantages and Features:

1. High-Quality Materials: The drive cable uses highly conductive copper conductors and high-quality outer sheath materials, ensuring stable power transmission efficiency over long-term operation.

2. Electromagnetic Interference (EMI) Protection: The built-in shielding layer effectively prevents electromagnetic interference (EMI), making it ideal for industrial automation systems requiring high electromagnetic compatibility.

3. Durability and Reliability: The PVC or polyethylene outer sheath offers excellent corrosion resistance and abrasion resistance, making it suitable for harsh environments and ensuring long-term stable operation.

4. Flexibility and Easy Installation: The cable is highly flexible, easy to install, and suitable for use in tight spaces or environments that require high flexibility.

5. Compliance with International Standards: The cable complies with international standards such as IEC and UL and has RoHS certification, ensuring environmental safety and reliable performance.

Applications:

• Industrial Automation: Used for connections between motors and drives in industrial automation systems, such as production lines, cranes, and other automated equipment.

• Motor Control Systems: Used for transmitting power and control signals in various types of motor control systems.

• Variable Frequency Drive (VFD) Systems: Used for connecting variable frequency drives to motors, ensuring stable power and signal transmission for efficient operation.

• Robotic Systems: Used for transmitting control and drive signals in robotics and automated equipment, ensuring precise movements.

• HVAC Systems: Used to connect motors and drives in HVAC systems, ensuring the proper operation of fans, pumps, and other equipment.

Precautions:

1. Installation Environment: Ensure that the cable is installed in a dry and well-ventilated environment, avoiding direct exposure to moisture, corrosive gases, or extreme temperatures.

2. Voltage and Current Matching: Ensure that the rated voltage and current of the cable match the requirements of the drive and motor to avoid overload.

3. Proper Grounding: Ensure the cable is properly grounded to enhance system safety and prevent electrical faults.

4. Regular Inspections: Periodically inspect the cable’s outer sheath and connectors to ensure no damage, preventing signal loss or power transmission failure.

5. Bend Radius: When wiring, ensure the cable’s minimum bend radius is not less than the specified value to avoid damage to the internal structure of the cable.

.
