ABB TB826 3BSE061637R1 Optical Media Converter

Product Information: ABB TB826 3BSE061637R1 Optical Media Converter

Detailed Specifications:

• Model: TB826 3BSE061637R1

• Type: Optical Media Converter

• Fiber Interface Type: 100Base-FX, supports multimode fiber

• Electrical Interface Type: 100Base-TX, supports standard RJ45 Ethernet interface

• Transmission Speed: 100 Mbps (Fast Ethernet)

• Transmission Distance:

  • Multimode fiber: up to 2 kilometers (depending on fiber type and wavelength)

• Operating Temperature Range: -40°C to +70°C

• Storage Temperature Range: -40°C to +85°C

• Power Supply: 24 V DC

• Power Consumption: Maximum 5 W

• Mounting Type: DIN Rail Mounting

• Protection Rating: IP20

• Dimensions: 120mm x 100mm x 45mm

• Weight: Approx. 0.3 kg

• Certifications: CE, UL, RoHS

• Redundancy Support: Supports link redundancy for high availability

• Electromagnetic Interference (EMI) Protection: Strong anti-EMI protection, suitable for industrial environments

Product Advantages and Features:

1. Optical-Electrical Conversion: The TB826 optical media converter enables conversion from electrical Ethernet signals to fiber optic signals, ideal for remote transmission applications like factory floors and remote equipment connections.

2. High-Speed Data Transmission: Supports 100 Mbps high-speed data transmission, meeting the needs of most industrial Ethernet applications, providing stable communication.

3. Long-Distance Transmission: The multimode fiber interface allows longer transmission distances (up to 2 kilometers), enabling high-speed data transfer between devices over large areas, such as between buildings or production zones.

4. Industrial-grade Reliability: The TB826 offers strong resistance to electromagnetic interference (EMI) and high temperature tolerance, making it suitable for harsh industrial environments like manufacturing shops and automated production lines.

5. Space-Saving and Easy Installation: The compact design supports DIN rail mounting, saving space and allowing easy installation in control cabinets and panels.

6. Link Redundancy Support: It supports link redundancy, automatically switching to a backup link in case of network failure, ensuring continuous and reliable network communication.

7. Wide Compatibility: Compatible with standard Ethernet devices and industrial control systems, it integrates easily with different brands and models, increasing system flexibility.

Applications:

• Industrial Automation Control: Used for network connections in industrial automation control systems, especially for linking production lines, factory floors, and remote monitoring systems.

• Energy Management and Monitoring: Used for high-speed data transmission between different areas in energy management systems, particularly in regions requiring fiber connections.

• Traffic Control: Used in intelligent transportation systems for data transmission between traffic signal control devices, surveillance cameras, and control centers.

• Building Automation: Used in building automation systems for network connections between floors and areas, enabling centralized management and control of facilities.

• Water Treatment and Environmental Monitoring: Applied in water treatment plants and environmental monitoring systems for remote monitoring and data transmission.

• Power Equipment: Used in electrical power stations and substations for communication between equipment and control systems, ensuring real-time data collection and monitoring.

Precautions:

1. Power Supply Stability: Ensure stable 24 V DC power supply. Voltage fluctuations can affect the device’s performance or cause failures.

2. Fiber Selection: Choose the appropriate fiber type and length based on the application to ensure the fiber supports the required transmission distance and bandwidth.

3. Installation Location: Ensure the installation location is dry, well-ventilated, and avoids exposure to excessive moisture or extreme temperatures.

4. Redundancy Configuration: If redundancy is required, ensure the two links are configured correctly and perform testing to ensure system reliability.

5. Regular Inspections and Maintenance: Periodically check the fiber and power connections, ensure there is no loose connection, and verify that the device is in good working condition to avoid signal loss or disruption.

The structure and details of the product：
