ABB MCD312-16IO1 Thyristor Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Information: ABB MCD312-16IO1 Thyristor Module

Detailed Specifications:

• Model: MCD312-16IO1

• Type: Thyristor Module

• Input Type:

  • Control Input: 24 V DC (common control signal type)

  • Signal Input: Supports digital and analog input signals

• Output Type:

  • Output Ports: Supports high-power DC output, suitable for driving large electric motors

  • AC Output: Suitable for three-phase AC power

• Power Requirements:

  • Input Voltage Range: 380-480 V AC (three-phase)

  • Output Voltage: Depends on drive requirements, suitable for controlling various electrical loads

• Current Rating: Max 16 A (for controlling and driving equipment)

• Operating Temperature Range: -10°C to +60°C

• Storage Temperature Range: -40°C to +85°C

• Protection Rating: IP20 (suitable for industrial environments)

• Communication Protocol: Supports Modbus RTU, Profibus DP, and other common industrial protocols

• Dimensions: 180mm x 120mm x 80mm

• Weight: Approx. 1.5 kg

• Certifications: CE, UL, RoHS certified

• Operating Frequency: 50/60 Hz (suitable for global power standards)

Product Advantages and Features:

1. High-Performance Control: The MCD312-16IO1 utilizes advanced thyristor technology for efficient control of high-power loads, particularly suitable for motor control in industrial power control systems.

2. Multiple Control Signal Inputs: The module supports various control signal types (e.g., 24V DC input, digital/analog signals), providing flexible integration into existing systems for precise control.

3. High Power Handling: The module supports up to 16A of current, making it suitable for controlling large power equipment such as motors and other industrial loads.

4. Durability and Reliability: It has excellent resistance to electrical interference and performs reliably in harsh industrial environments with an IP20 protection rating.

5. High Compatibility: The module supports Modbus RTU, Profibus DP, and other popular communication protocols, allowing seamless integration with existing control systems.

6. Precision Control and Feedback: Provides precise current and voltage control, ensuring system stability and safety, ideal for applications requiring real-time feedback and adjustments.

7. Compact Design: Its compact size makes it ideal for installation in control panels or other confined spaces, saving installation space and making maintenance and replacement easier.

Applications:

1. Motor Control: The MCD312-16IO1 is commonly used in motor drive systems for precise control of motor start/stop, speed regulation, and direction control in industrial applications.

2. Power Control Systems: Used in power systems to control large electrical loads such as industrial equipment and heating systems, ensuring efficient power transmission and control.

3. Automated Production Lines: Applied in automated production lines for motor drive and load control, ensuring stable operation of equipment in the production process.

4. Building Automation: Used in building automation systems for HVAC, elevators, pumps, and other equipment control, ensuring efficient and reliable operation.

5. Wind Power and Energy Management: Applied in wind power systems for power control and regulation, ensuring efficient energy usage and transmission.

6. Welding and Heating Control: Used in welding equipment and industrial heaters for current control, ensuring precise regulation and safety in heating processes.

Precautions:

1. Power Requirements: Ensure the input voltage is within the 380-480 V AC range, as voltage fluctuations may affect module performance.

2. Cooling Requirements: While the module has good heat dissipation capabilities, additional cooling may be required under high load conditions to prevent overheating.

3. Wiring Considerations: Ensure all wiring is secure, and avoid loose connections at terminals to reduce the risk of electrical faults.

4. Installation Location: Install the module in a dry, well-ventilated area and avoid exposure to excessive moisture or extreme temperatures.

5. Regular Inspection: Periodically check the module’s operating status and electrical connections to ensure no damage, loose connections, or power interruptions.

Please make an inquiry for more models
