ABB DATX132 (3ASC25H216A) Controller Module

1. Key Parameters

• Product Model: DATX132
• Order Code: 3ASC25H216A
• Product Series: ABB DATX Series Distributed Controller Modules (Compatible with ABB 800xA DCS/AC800M PLC Systems)
• Core Function: Executes real-time control logic (sequence, regulatory, safety); integrates with field I/O devices (sensors, actuators); communicates with DCS/PLC via high-speed protocols; monitors system health and transmits diagnostic data
• Electrical Specifications:

  Parameter	Details	Performance Metrics
  Power Supply	- Input Voltage: 5V DC ±5% (system backplane) + 24V DC ±10% (I/O circuits) - Current Consumption: 1.5A (5V DC, normal); 0.4A (24V DC, I/O) - Power Consumption: ≤7.5W (5V×1.5A) + ≤9.6W (24V×0.4A) = ≤17.1W total	Draws power from ABB automation rack backplanes, avoiding external wiring complexity
  Processing Performance	- Processor: Dual-core 32-bit industrial CPU (300 MHz clock speed, with FPU) - Control Logic Execution: 1ms cycle time for 1000+ I/O points - Program Memory: 1MB flash (for control programs); 512KB RAM (real-time data) - Supported Languages: IEC 61131-3 (LD, FBD, ST, SFC, IL)	Executes complex regulatory control (e.g., cascade PID) and sequence logic (e.g., turbine startup) with minimal latency
  I/O Integration	- Native I/O Support: ABB AI800/DI800 analog/digital modules (via PROFINET) - Max I/O Capacity: 2048 digital points + 512 analog points - I/O Update Rate: 10ms (analog); 1ms (digital) - Signal Compatibility: 4~20mA, 0~10V (analog); 24V DC (digital, sinking/sourcing)	Scales to large process plants (e.g., 500+ sensors in a refinery) without performance degradation
  Communication Protocols	- Backplane: ABB AC 800M backplane (1Gbps, for DCS integration) - Fieldbus: PROFINET IRT (100Mbps, real-time), Modbus TCP (100Mbps) - Safety Protocol: PROFIsafe (for SIL 2/3 loops) - Diagnostic Data: Transmitted via OPC UA (for remote monitoring)	Enables real-time control (PROFINET IRT) and secure data sharing (OPC UA) with SCADA/HMI systems
  Safety & Diagnostics	- Safety Rating: IEC 61508 SIL 2 (single module); SIL 3 (redundant configuration) - Fault Detection: Hardware self-test (CPU, memory, communication); I/O signal validation (out-of-range, short circuit) - Fault Logging: 200+ timestamped fault codes; stores last 200 events (non-volatile)	Supports safety-critical loops (e.g., emergency shutdown for gas turbines)
  Isolation Ratings	- I/O to Backplane: 2kVrms (1min dielectric test) - Communication to Power: 1.5kVrms (1min dielectric test) - Analog Input to Ground: 1kVrms (1min dielectric test)	Protects sensitive control circuits from high-voltage transients (e.g., motor startup surges)

• Mechanical Specifications:
  • Housing Material: FR4 glass-epoxy circuit board (UL94 V-0); aluminum heat sink (for CPU cooling); metal EMI shield
  • Dimensions (W×H×D): 160mm × 320mm × 45mm (19-inch rack-mounted, 1U height; fits ABB standard racks)
  • Mounting: Rack-mounted via slide rails (compatible with ABB AC 800M racks); secured with 2 locking screws (anti-vibration)
  • Weight: Approximately 600g
  • Connectors: 1× backplane connector (power/communication); 2× RJ45 (PROFINET/Modbus TCP); 1× D-sub 9-pin (diagnostic port); 1× USB (configuration)
  • LED Indicators:
    • Power (PWR): Green (5V normal) + Yellow (24V normal); Red (power fault)
    • CPU (CPU): Green (normal); Flashing green (processing); Red (CPU fault)
    • Communication (COM): Green (PROFINET active); Yellow (Modbus active); Red (comm error)
    • Safety (SAFE): Green (SIL loop normal); Red (safety fault)
• Environmental Ratings:
  • Operating Temperature Range: -25℃~+70℃ (-13℉~158℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: 5%~95% RH (non-condensing, 40℃)
  • Vibration Resistance: 10~500Hz, 2g acceleration (IEC 60068-2-6; no data loss)
  • Shock Resistance: 30g (11ms duration, IEC 60068-2-27; no hardware damage)
  • EMC Compliance: EN 61000-6-2 (industrial immunity); EN 61000-6-3 (emissions, Class A) | Resists noise from high-power equipment
• Compliance Standards: IEC 61131-3, EN 61010-1, UL 508C, CE, RoHS, IEC 61508 (SIL 2/3), ISO 13849-1 (PL d)

2. Key Features

• Dual-Core CPU for High-Speed Control: 300 MHz dual-core industrial CPU delivers 1ms cycle time for 1000+ I/O points—executes simultaneous regulatory control (e.g., PID for pressure) and sequence logic (e.g., valve actuation sequences), eliminating bottlenecks in complex processes (e.g., refinery distillation columns).
• ABB 800xA DCS Native Compatibility: Uses ABB’s 1Gbps backplane communication for seamless integration with 800xA DCS—shares real-time data (e.g., process variables, fault codes) without protocol conversion, reducing latency by 50% vs. third-party controllers.
• PROFINET IRT for Real-Time Fieldbus: Supports PROFINET IRT (Isochronous Real-Time) with 100Mbps transfer rate—synchronizes I/O updates (1ms digital, 10ms analog) across 2000+ points, critical for time-sensitive processes (e.g., turbine speed control, paper machine web tension).
• SIL 2/3 Safety Compliance: Certified for IEC 61508 SIL 2 (single) and SIL 3 (redundant)—enables safety-critical loops (e.g., emergency shutdown for gas leaks, overpressure protection for boilers) without additional safety relays, simplifying system design.
• Scalable I/O Capacity: Integrates with ABB AI800/DI800 I/O modules to support 2048 digital + 512 analog points—scales from small machines (e.g., 50 I/O for a mixer) to large plants (e.g., 2000 I/O for a coal-fired power plant), avoiding controller replacement during expansion.
• Rugged Environmental Tolerance: -25℃~+70℃ temperature range, 2g vibration resistance, and 95% humidity tolerance—operates reliably in harsh sites (e.g., arctic oil rigs, desert solar plants, coastal refineries) without climate-controlled enclosures.
• OPC UA for Remote Monitoring: Transmits diagnostic data via OPC UA—enables remote access to fault logs, CPU load, and I/O status (e.g., from a central control room to a remote pump station), reducing on-site maintenance visits by 40%.

3. Application Fields

• Power Generation (Turbines & Boilers): Primary application—turbine and boiler control:
  • Gas Turbine Control: Installed in ABB 800xA DCS for 100MW+ gas turbines; uses PROFINET IRT to sync 1ms speed feedback (from encoders) with fuel valve actuation, maintaining ±0.1% speed accuracy for grid stability; SIL 3 redundancy prevents shutdowns from controller faults.
  • Boiler Water Level Control: Executes cascade PID logic to regulate feedwater valves (analog outputs) based on level sensors (4~20mA inputs); PROFINET IRT ensures 10ms updates, preventing boiler dry-fire or overflow—critical for coal-fired power plants.
• Oil & Gas (Refineries & Pipelines): Process control for refineries and pipelines:
  • Refinery Distillation Columns: Controls temperature (analog inputs) and valve positions (analog outputs) across 500 I/O points; dual-core CPU runs simultaneous PID loops for each column tray, optimizing hydrocarbon separation and increasing yield by 5%.
  • Pipeline Pump Stations: Monitors pressure (4~20mA) and flow (digital inputs) via Modbus TCP; executes sequence logic to start/stop pumps based on pipeline demand; OPC UA transmits status to a central SCADA, enabling remote troubleshooting.
• Pulp & Paper Manufacturing: Control for paper machines and digesters:
  • Paper Machine Web Tension: Uses PROFINET IRT to sync 1ms tension sensor data (digital inputs) with roller speed actuators (analog outputs); maintains ±1% tension, reducing paper breaks by 30% in high-speed (1000m/min) machines.
  • Pulp Digester Control: Runs SFC (Sequential Function Chart) logic to coordinate chemical injection, pressure, and temperature (200 I/O points) during pulp cooking; SIL 2 compliance ensures safe shutdown if pressure exceeds limits.
• Mining & Minerals (Conveyors & Crushers): Control for mining equipment:
  • Long-Distance Conveyors: Monitors 500 digital inputs (belt alignment, emergency stops) and controls 100 analog outputs (motor speed, brake actuators); PROFINET IRT syncs 1ms stop signals across 1km conveyors, preventing belt damage from misalignment.
  • Crusher Load Control: Adjusts feeder speed (analog output) based on crusher current (analog input) via PID logic; 2g vibration resistance withstands crusher vibrations, while -25℃ low-temperature rating works in northern mining sites.
• Water & Wastewater (Pumps & Treatment Plants): Control for water infrastructure:
  • Wastewater Treatment Aeration: Controls 200 aerator blowers (digital outputs) based on dissolved oxygen sensors (4~20mA inputs); OPC UA transmits energy usage data to a BMS, optimizing blower runtime and reducing energy costs by 25%.
  • Water Distribution Pumps: Uses Modbus TCP to communicate with remote pressure sensors; executes logic to start/stop pumps (digital outputs) during peak demand; SIL 2 compliance ensures safe shutdown if pump pressure exceeds limits.

4. Precautions

• System Compatibility (Critical): Use exclusively with ABB 800xA DCS and AC800M PLCs—Never integrate with non-ABB DCS (e.g., Siemens PCS 7, Emerson DeltaV); incompatible backplane/protocol will cause communication failures, safety loop errors, or I/O desynchronization. Verify compatibility via ABB’s technical data sheet.
• Installation & Wiring:
  • Backplane Power Isolation: Disconnect the entire rack’s power (5V backplane + 24V I/O) before installation—live backplane pins risk short circuits (damaging the CPU) or electric shock. Use insulated tools and lockout/tagout; confirm power-off with a multimeter.
  • PROFINET Cable Requirements: Use shielded PROFINET IRT cables (CAT 5e or higher) with proper grounding—unshielded cables or poor grounding cause 50/60Hz noise in I/O signals (e.g., false overtemp alerts), leading to incorrect control actions.
  • Redundant Configuration Wiring: For SIL 3 redundancy, wire both controllers to the same I/O modules and backplane—unsymmetrical wiring (e.g., one controller missing a safety input) invalidates SIL 3 compliance, increasing safety risks.
• Configuration & Calibration:
  • PROFINET IRT Cycle Setup: Configure PROFINET IRT cycles (1ms for digital, 10ms for analog) via ABB Control Builder M—incorrect cycle times (e.g., 50ms for turbine speed) cause latency, leading to process overshoot (e.g., turbine speed spikes).
  • Safety Loop Validation: After configuring SIL loops, test fault injection (e.g., simulate a sensor short circuit)—verify the controller triggers a safety shutdown within 100ms; failure to meet timing invalidates SIL certification, requiring reconfiguration.
• Fault Handling & Maintenance:
  • Redundant Controller Switchover: In SIL 3 systems, test switchover (e.g., power off the primary controller) monthly—ensure the secondary controller takes over within 10ms; slow switchover (＞50ms) causes process disruptions (e.g., boiler pressure fluctuations).
  • Firmware Updates: Use only ABB-approved firmware (via USB or OPC UA)—mismatched firmware (e.g., AC800M firmware on DATX132) disables PROFINET IRT and safety functions; back up control programs before updating to avoid data loss.
• Environmental Limitations:
  • Temperature & Contamination: Avoid operating above +70℃ or in dusty environments—high temperatures degrade CPU performance (cycle time increases by 10% per 10℃ above 60℃), while dust accumulation on heat sinks causes overheating. Use air filters and cooling fans for high-temperature sites.
  • EMI Sources: Install the rack at least 2m away from high-voltage cables (e.g., 35kV power lines) and large motors—EMI interference corrupts PROFINET signals, leading to I/O desynchronization (e.g., valve actuation delayed by 100ms).

The structure and details of the product：
