ABB ACS510-01-046A-4 Industrial Frequency Converter

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB ACS510-01-046A-4 is an industrial frequency converter designed for controlling AC induction motors. It offers precise speed control, energy optimization, and motor protection for pumps, fans, conveyors, and general machinery. The ACS510 series is ideal for small to medium industrial automation applications.

This model has a rated power of 4 kW, rated current of 10 A, and operates on 3-phase 380–480 V AC input, suitable for industrial installations.

2. Main Technical Specifications

• Model: ACS510-01-046A-4

• Series: ACS510

• Rated Power: 4 kW

• Rated Current: 10 A

• Input Voltage: 3×380–480 V AC

• Output Voltage: 0–480 V AC

• Output Frequency Range: 0–650 Hz

• Control Method: V/Hz control, vector control optional

• Overload Capability: 150% for 1 minute

• Protection Functions:

  • Overcurrent, overvoltage, undervoltage

  • Overtemperature protection

  • Short-circuit protection

• Communication Interfaces: Modbus RTU (optional Profibus, CANopen)

• Operation Panel: LCD with parameter setting

• Operating Temperature: -10°C to +50°C

• Humidity: 5–95% RH (non-condensing)

• Protection Class: IP20

• Mounting: Wall or cabinet mount

• Dimensions & Weight: Approx. 270×210×180 mm, 8 kg

3. Advantages and Features

1. Precise Control and Energy Saving

• V/Hz or vector control ensures smooth start and accurate motor speed.

• Energy-efficient operation reduces industrial energy consumption.

2. User-Friendly

• Built-in LCD panel shows parameters and fault codes.

• Quick parameter copy function for multiple units.

3. Safety and Protection

• Multiple motor and converter protections extend equipment life.

• Overcurrent, overvoltage, overtemperature protections enhance reliability.

4. Communication and Integration

• Built-in Modbus RTU, optional Profibus or CANopen for PLC/SCADA integration.

• Easy integration into industrial automation systems.

5. Compact and Durable

• Compact design saves space.

• Industrial-grade components withstand high temperature, dust, and vibration.

4. Typical Application Areas

• Industrial pumps and fans

• Conveyor and machinery drives

• HVAC systems and ventilation control

• Packaging, food & beverage, chemical, mining industries

• Small to medium factory automation applications

5. Precautions

1. Verify power supply matches rated parameters before connection.

2. Set correct motor parameters to prevent overload or overheating.

3. Install in a well-ventilated area; avoid high temperature, humidity, or dust.

4. Ensure wiring complies with electrical standards and is properly grounded.

5. Avoid frequent power cycling; use proper circuit protection.

6. Regularly check cooling fans, terminals, and cleanliness.

7. Check panel fault codes for troubleshooting before taking action.
